(888) 312-8812 Login SignupCENTRIC 120.67046 Centric Premium Brake Rotor
Tap to view 4 more
$6599
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Aug 24
CENTRIC 120.67046 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.67046 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 26.740 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 12.150 |
| Discard Thickness | 33.530 MM |
| Discard Thickness | 1.320 IN |
| Nominal Thickness | 1.398 IN |
| Nominal Thickness | 35.500 MM |
| Hat Finish | Painted |
| Overall Height | 4.016 IN |
| Overall Height | 102.000 MM |
| Outside Diameter | 326.500 MM |
| Outside Diameter | 12.854 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 122.300 MM |
| Center Hole Diameter | 4.815 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 0.665 IN |
| Stud/Lug Hole Diameter | 16.900 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890036463 |
CENTRIC 120.67046 Cross References
| Brand | Part Number |
|---|---|
| 76920, BD125745 | |
| N/A | FR05066, BD125745, BD125745E, E125-72-051, 153145283, 6491170, 5393, 5393G, 5015230AA, 52009740AB, 05015230AA, 145283, 4886920, 86920, AR8746, E12572051, E12390, 120.67046, 5393GT, 8746, 5393DSR, YH145283, 5393DSL, 27126, X51342, 76920PEP, 19909, 8940046, 90040088 |
| NEOTEK | 107051GF |
| Neotek Premium Drums and Rotors | 107051GF |
| RAYBESTOS | 76920, 76920FZN, 76920PER, 76920R, 76920R2 |
| Raybestos Brakes | 76920, 76920FZN, 76920PER, 76920R |
| WAGNER | BD125745, BD125745E |
CENTRIC 120.67046 Fits Vehicles
- Dodge Ram 4000 (2000-2002)
- Dodge Ram 3500 (2000-2002)
- Dodge Ram 2500 (2000-2002)
