(888) 312-8812 Login SignupCENTRIC 120.62042 Centric Premium Brake Rotor
Tap to view 4 more
$91.31
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.62042 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.62042 Specifications
Product Attributes
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 20.500 |
| Disc Mounting [cntrc] | Behind the Hub |
| Weight [cntrc] Kgs | 9.320 |
| Discard Thickness | 30.860 MM |
| Discard Thickness | 1.215 IN |
| Nominal Thickness | 1.295 IN |
| Nominal Thickness | 32.900 MM |
| Hat Finish | Painted |
| Overall Height | 70.000 MM |
| Overall Height | 2.756 IN |
| Outside Diameter | 317.500 MM |
| Outside Diameter | 12.500 IN |
| Mounting Bolt Hole Quantity | 8 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 137.400 MM |
| Center Hole Diameter | 5.409 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Mounting Bolt Hole Diameter | 16.400 MM |
| Mounting Bolt Hole Diameter | 0.646 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890042723 |
CENTRIC 120.62042 Cross References
| Brand | Part Number |
|---|---|
| 56242, BD61918 | |
| N/A | BD61918, BD61918E, E125-67-047, 6493970, 64 93 970, 5593, 107212, 5593G, 18060224, 15564912, 15564913, 15661727, 15981322, 15981339, 52007851, 12549136, 4798315, 141477, 4886242, 86242, 607, AR8242, D17540, E9242, E12567047, 120.62042, 5593DSR, YH141477, SD5593L, SD5593R, 5593DSL, 27044, X50654, BR1907, 8936042, 65505, 177709, 177767, 18A489, 18A489A, 90040045 |
| RAYBESTOS | 56242, 56242FZN, 56242PER, 56242R, 56242R2 |
| Raybestos Brakes | 56242, 56242FZN, 56242PER, 56242R |
| WAGNER | BD61918, BD61918E |
CENTRIC 120.62042 Fits Vehicles
- GMC K3500 (1988-2000)
- GMC K2500 Suburban (1992-1999)
- GMC K2500 (1989-2000)
- GMC K1500 Suburban (1994-1999)
- Chevrolet Suburban 2500 (2000)
- Dodge Ram 2500 (1994-1997)
- Chevrolet K3500 (1988-2000)
- Chevrolet K2500 Suburban (1992-1999)
- Chevrolet K2500 (1989-2000)
- Chevrolet K1500 Suburban (1994-1999)
