CENTRIC 120.48011 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.48011 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] Mm | 153.800 |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Lbs | 15.100 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 6.860 |
| Vane Style [cntrc] | Straight |
| Hat Id [cntrc] In | 6.055 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 0.906 IN |
| Discard Thickness | 23.000 MM |
| Nominal Thickness | 25.000 MM |
| Nominal Thickness | 0.984 IN |
| Hat Finish | Painted |
| Overall Height | 49.200 MM |
| Overall Height | 1.937 IN |
| Stud/Lug Hole Diameter | 12.700 MM |
| Stud/Lug Hole Diameter | 0.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Mounting Bolt Hole Circle Diameter | 114.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.488 IN |
| Center Hole Diameter | 61.800 MM |
| Center Hole Diameter | 2.433 IN |
| Bearings Included | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Outside Diameter | 11.598 IN |
| Outside Diameter | 294.600 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890338277 |
CENTRIC 120.48011 Cross References
| Brand | Part Number |
|---|---|
| 980509, BD180049 | |
| N/A | 120.48011, BD180049, BD180049E, E125-53-016, 5321, YH200369, 44641, 31454G, 5521165J00, 5521165J01, 980509, 48880509, 31454, DDF1635, DF7371S, 90001014, E12553016 |
| NEOTEK | 1069027GF |
| Neotek Premium Drums and Rotors | 1069027GF |
| RAYBESTOS | 980509FZN, 980509R |
| Raybestos Brakes | 980509FZN, 980509R |
| WAGNER | BD180049E, BD180049 |
CENTRIC 120.48011 Fits Vehicles
- Suzuki Grand Vitara (2006-2013)
