Centric 120.40023 - Centric Premium Brake Rotor
$3649
MSRP: $48.69
Save: $12.20
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 4 |
| Weight [cntrc] Lbs | 10.500 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 4.770 |
| Discard Thickness | 0.748 IN |
| Discard Thickness | 19.000 MM |
| Nominal Thickness | 21.000 MM |
| Nominal Thickness | 0.827 IN |
| Hat Finish | Coated |
| Overall Height | 45.000 MM |
| Overall Height | 1.772 IN |
| Outside Diameter | 9.449 IN |
| Outside Diameter | 240.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.402 IN |
| Center Hole Diameter | 61.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 0.504 IN |
| Stud/Lug Hole Diameter | 12.800 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890031284 |
Part Interchanges
- Raybestos Brakes 96147FZN
- Raybestos Brakes 96147R
- Raybestos Brakes 96147
- Neotek Premium Drums and Rotors 106209GF
- BD125006
- BD125006E
- 64 72 310
- 6472310
- 45251SR3A10
- 31029
- 31029G
- 106209
- 45251SH0A00
- 45251SH1A00
- 45251SH3A00
- 45251SR3A00
- 45251SR3A10A
- 45251SH3A10
- 452515H3A00
- 141581
- 86147
- 4886147
- 141
- JBR525
- D17551
- 31029HC
- 1.1925.2.4
- 1192524
- 120.40023
- HO211V
- 31029DSR
- 1407-78014
- YH141581
- 31029DSL
- X50679
- 25507
- BR1664
- DDF447
- DF1436
- 19740
- 8908024
- 63275
- 142888
- 90059018
CENTRIC 120.40023 Cross Reference
We have 6 alternatives for the 120.40023 by CENTRIC:
Fits Vehicles
- Honda CRX (1990-1991)
- Honda Civic del Sol (1993-1997)
- Honda Civic (1990-2000)
