(888) 312-8812 Login SignupCENTRIC 320.66052F Centric GCX Rotor with Full Coating
$6899
Limited availability at this price!
In Stock
Get it by Friday, Feb 6
CENTRIC 320.66052F Part Description
CENTRIC 320.66052F Specifications
Product Attributes
| Weight [cntrc] Kgs | 8.180 |
| Misc Holes [cntrc] | 2 |
| Max Pb Drum Dia [cntrc] Mm | 211.700 |
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 18.000 |
| Vane Style [cntrc] | Straight |
| Max Pb Drum Dia [cntrc] In | 8.335 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 18.500 MM |
| Discard Thickness | 0.728 IN |
| Nominal Thickness | 20.000 MM |
| Nominal Thickness | 0.787 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 85.000 MM |
| Overall Height | 3.346 IN |
| Outside Diameter | 12.795 IN |
| Outside Diameter | 325.000 MM |
| ABS Tone Ring Included | No |
| Stud/Lug Hole Diameter | 0.520 IN |
| Stud/Lug Hole Diameter | 13.200 MM |
| Stud/Lug Hole Quantity | 6 |
| Mounting Bolt Hole Circle Diameter | 5.000 IN |
| Mounting Bolt Hole Circle Diameter | 127.000 MM |
| Center Hole Diameter | 78.700 MM |
| Center Hole Diameter | 3.098 IN |
| Bearings Included | No |
| Nominal Drum Diameter | 8.276 IN |
| Nominal Drum Diameter | 210.200 MM |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
CENTRIC 320.66052F Cross References
| Brand | Part Number |
|---|---|
| MAGMA PRODUCTS | PSR225226 |
CENTRIC 320.66052F Fits Vehicles
- Chevrolet Trailblazer EXT (2002-2006)
- GMC Envoy XL (2002-2006)
- GMC Envoy XUV (2004-2005)
- Oldsmobile Bravada (2002-2004)
- Isuzu Ascender (2003-2008)
- Saab 9-7x (2005-2009)
- GMC Envoy (2002-2009)
- Chevrolet Trailblazer (2002-2009)
- Chevrolet SSR (2003-2006)
- Buick Rainier (2004-2007)
