(888) 312-8812 Login SignupCENTRIC 320.66043F Centric GCX Rotor with Full Coating
$9149
Limited availability at this price!
In Stock
Get it by Monday, Feb 16
CENTRIC 320.66043F Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating
Features & Benefits
- For the best corrosion resistance
- RS200™ Zinc-Aluminum Rich Coating
- Optimal Surface Finish
- For consistent and confident braking from the first stop
- Carbon Enhanved Advanced Metallurgy
- For optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- For heat capacity and strength
- Low Initial Lateral Run-Out
- For smooth vibration free stopping
- Precision Balance
- For vibration free performance
CENTRIC 320.66043F Specifications
Product Attributes
| Weight [cntrc] Kgs | 10.910 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Lbs | 24.000 |
| Disc Mounting [cntrc] | Floating / DIH |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Discard Thickness | 26.500 MM |
| Discard Thickness | 1.043 IN |
| Nominal Thickness | 29.000 MM |
| Nominal Thickness | 1.142 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 85.700 MM |
| Overall Height | 3.374 IN |
| Outside Diameter | 330.000 MM |
| Outside Diameter | 12.992 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 206.000 MM |
| Nominal Drum Diameter | 8.110 IN |
| Bearings Included | No |
| Center Hole Diameter | 4.630 IN |
| Center Hole Diameter | 117.600 MM |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 16.500 MM |
| Stud/Lug Hole Diameter | 0.650 IN |
CENTRIC 320.66043F Cross References
CENTRIC 320.66043F Fits Vehicles
- GMC Sierra 1500 (2004)
- GMC Sierra 1500 HD Classic (2007)
- Chevrolet Silverado 1500 HD Classic (2007)
- GMC Sierra 2500 (1999-2004)
- Hummer H2 (2003-2009)
- GMC Yukon XL 2500 (2000-2007)
- Chevrolet Silverado 2500 (1999-2004)
- GMC Sierra 2500 HD (2005)
- GMC Sierra 1500 HD (2001-2003, 2005-2006)
- GMC Savana 3500 (2004-2019, 2021-2022)
- GMC Savana 2500 (2003-2021)
- Chevrolet Suburban 2500 (2000-2007)
- Chevrolet Silverado 1500 HD (2001-2003, 2005-2006)
- Chevrolet Silverado 2500 HD (2005)
- Chevrolet Silverado 1500 (2004-2005)
- Chevrolet Express 3500 (2004-2022)
- Chevrolet Express 2500 (2003-2009, 2011-2022)
- Chevrolet Avalanche 2500 (2002-2006)
