CENTRIC 320.65103F Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating
Features & Benefits
- For the best corrosion resistance
- RS200™ Zinc-Aluminum Rich Coating
- Optimal Surface Finish
- For consistent and confident braking from the first stop
- Carbon Enhanved Advanced Metallurgy
- For optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- For heat capacity and strength
- Low Initial Lateral Run-Out
- For smooth vibration free stopping
- Precision Balance
- For vibration free performance
CENTRIC 320.65103F Specifications
Product Attributes
| Weight [cntrc] Lbs | 25.000 |
| Misc Holes [cntrc] | 2 |
| Vane Style [cntrc] | Straight |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 11.360 |
| Max Pb Drum Dia [cntrc] In | 9.024 |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] Mm | 229.200 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Stud/Lug Hole Diameter | 0.602 IN |
| Stud/Lug Hole Diameter | 15.300 MM |
| Stud/Lug Hole Quantity | 7 |
| Mounting Bolt Hole Circle Diameter | 5.906 IN |
| Mounting Bolt Hole Circle Diameter | 150.000 MM |
| Center Hole Diameter | 90.000 MM |
| Center Hole Diameter | 3.543 IN |
| Bearings Included | No |
| Nominal Drum Diameter | 8.992 IN |
| Nominal Drum Diameter | 228.400 MM |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Outside Diameter | 348.000 MM |
| Outside Diameter | 13.701 IN |
| Overall Height | 3.386 IN |
| Overall Height | 86.000 MM |
| Hat Finish | Coated |
| Disc Finish | Fully Coated |
| Nominal Thickness | 0.787 IN |
| Nominal Thickness | 20.000 MM |
| Discard Thickness | 0.728 IN |
| Discard Thickness | 18.500 MM |
CENTRIC 320.65103F Cross References
CENTRIC 320.65103F Fits Vehicles
- Ford Lobo (2004-2010)
- Ford F-150 Heritage (2004)
- Lincoln Mark LT (2006-2008)
- Ford F-150 (2004-2011)
