CENTRIC 120.40064 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.40064 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 4 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 7.730 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 17.000 |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26.000 MM |
| Nominal Thickness | 1.098 IN |
| Nominal Thickness | 27.900 MM |
| Hat Finish | Painted |
| Overall Height | 47.500 MM |
| Overall Height | 1.870 IN |
| Outside Diameter | 296.100 MM |
| Outside Diameter | 11.657 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.764 IN |
| Center Hole Diameter | 70.200 MM |
| Mounting Bolt Hole Circle Diameter | 4.654 IN |
| Mounting Bolt Hole Circle Diameter | 118.200 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.600 MM |
| Stud/Lug Hole Diameter | 0.575 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890320944 |
CENTRIC 120.40064 Cross References
| Brand | Part Number |
|---|---|
| 980290, BD126353 | |
| ADVICS | C6F087U |
| N/A | 120.40064, BD126353, BD126353E, E125-45-069, BR3136802, 31368GT, 31368, YH145604, 1407-75103, 25935, 31368G, 45251SHJA00, 880294, 2031368, 19375, 90059049, E12545069, 31368HC |
| NEOTEK | 106264GF |
| Neotek Premium Drums and Rotors | 106264GF |
| PRONTO | BR3136802 |
| RAYBESTOS | 980290, 980290FZN, 980290R, 980290R2 |
| Raybestos Brakes | 980290, 980290FZN, 980290R |
| WAGNER | BD126353, BD126353E |
CENTRIC 120.40064 Fits Vehicles
- Honda Odyssey (2005-2010)
