Carlson H5077 - DISC HOUSING BOLT
$1249
MSRP: $13.46
Save: $0.97
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CARLSON part description
Buyers Guide:
- CHEVROLET-C4500 KODIAK
- C5500 KODIAK
- C6500 KODIAK
- C7500 KODIAK
- W4500 TILTMASTER
- W5500 TILTMASTER
- W5500HD TILTMASTER (06-03); FORD-E-550 ECONOLINE SUPER DUTY
- E-550 SUPER DUTY
- F-450 SUPER DUTY
- F-550 SUPER DUTY
- LCF (11-02); GMC-C4500 TOPKICK
- C5500 TOPKICK
- C6500 TOPKICK
- C7500 TOPKICK
- W4500 FORWARD
- W5500 FORWARD (06-03)
Product Description
Disc Brake Caliper Guide Pin
Features & Benefits
- This part matches Original Equipment (OE) quality specifications
- Easy and fast replacement
- Ensures the brake pads are meeting the rotors at the correct angle for an even braking system
- Corrosion resistant coating for long-lasting durability against harsh roads
- Manufactured with quality materials to suppress high stress levels
- Helps deliver a quieter, more efficient braking system
Product Attributes
| Instructions Included | No |
| Dust Boots Included | No |
| CALIPER BOLT HEAD TYPE | Hex |
| Thread Length (mm) | 31.8 |
| Shoulder Length (In) | 2-1/3 |
| Number of Bolts | 2 |
| Length (in) | Bolt: 3-3/4 Sleeve: 2-7/8 |
| Head Size (in) | 5/8Inch |
| Color | Zinc |
| Thread Size | M10-1.50 |
| Sleeve Included | Yes |
| Number Of Sleeves | 2 |
| Length (mm) | Bolt: 99 Sleeve: 72.9 |
| Head Size (MM) | 16 |
| Diameter (in) | Bolt: 2/5 Sleeve: 4/7 |
| Washers Included | No |
| Thread Length (In) | 1-1/4 |
| Nuts Included | No |
| Material | Steel |
| Caliper Grease Included | No |
Additional Information
| Harmonized Tariff Code (Schedule B) | 7318290000 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 7318290000 |
| UPC | 00085499154106 |
Part Interchanges
Fits Vehicles
- Ford F-59 Commercial Stripped Chassis (2011-2019)
- Ford F-53 Motorhome Chassis (1999-2004, 2006-2009, 2011-2019)
- Ford LCF (2006-2007)
- GMC C7500 Topkick (2003-2005)
- GMC C6500 Topkick (2003-2006)
- GMC C5500 Topkick (2003-2006)
- Chevrolet C7500 Kodiak (2003-2005)
- Chevrolet C6500 Kodiak (2003-2006)
- Chevrolet C5500 Kodiak (2003-2006)
- GMC C4500 Topkick (2003-2006)
- Chevrolet C4500 Kodiak (2003-2006)
- Ford E-550 Super Duty (2003)
- Ford E-550 Econoline Super Duty (2002)
- Ford F-550 Super Duty (1999-2016)
- Ford F-450 Super Duty (1999-2016)
