MERITOR FS9978 Part Description
Manufacturer
Product Description
Air Suspension Spring
Meritor Air Suspension Spring
The Meritor Air Suspension Spring uses a reversible sleeve design with 9.00-inch top bead plate diameter, 10.16-inch bottom bead plate diameter, and 7.90-inch collapsed height. Its air volume and rubber sleeve shape turn pressure into ride height control while separating the frame from road shock. During suspension spring replacement, the Meritor FS9978 returns the air spring position to the ride system.
| Aftermarket Extended Warranty - General | 3 Years / 300K Miles |
| Bead Plate Diameter Bottom | 10.16 in. |
| Bead Plate Diameter Top | 9.00 in. |
| Collapsed Height | 7.90 in. |
| Convoluted Style | 1T Reversible Sleeve |
| Max. Height | 18.00 in. |
| Part Diameter | 10.12 in. |
| Piston Height | 5.69 in. |
| Stud Configuration-Bottom | 1 |
| Stud Configuration-Top | 2 |
| Stud Mount-Bottom Flat | Stud |
| Stud Mount-Top Flat | Stud |
| VMRS Code | 016-008-000 |
Meritor Air Suspension Spring
Meritor air suspension spring protects tractors and trailers from road shocks and keep your ride a comfortable one. This aftermarket air spring covers a wide range of OEM specifications at affordable prices.
Features & Benefits
- Lightweight, high-strength pistons with support washers provide exceptional strength and durability
- Made of premium-grade steel and aluminum with electrostatic coating for oxidation resistance
- Special chromium coating on bead plate protects against rust, corrosive chemicals, and harsh operating environments
- Air spring replacement can correct ride height loss under load
MERITOR FS9978 Specifications
Product Attributes
| Aftermarket Extended Warranty - General | 3 Years / 300K Miles |
| Bead Plate Diameter Bottom | 10.16 in. |
| Bead Plate Diameter Top | 9.00 in. |
| Brand | Meritor |
| Collapsed Height | 7.90 in. |
| Convoluted Style | 1T Reversible Sleeve |
| Max. Height | 18.00 in. |
| Pallet Quantity | 32 |
| Part Diameter | 10.12 in. |
| Piston Height | 5.69 in. |
| Product Category | Genuine OE Product |
| Stud Configuration-bottom | 01 |
| Stud Configuration-top | 02 |
| Stud Mount-bottom Flat | Stud |
| Stud Mount-top Flat | Stud |
| Weight | 14.01 |
| Air Spring Type | Reversible Sleeve |
| Max Height | 18.00 in. |
MERITOR FS9978 Cross References
| Brand | Part Number |
|---|---|
| Automann | 566CT67588, AB1DK23IA959, AB1DK23IP959 |
| CONTITECH | 91014P959 |
| Continental-ContiTech | 67588, 91014P959 |
| DAYTON PARTS BATCO | 3529978, S28929 |
| FIRESTONE | W013589978 |
| Firestone Ride-Rite | W013589978 |
| HENDRICKSON | S28929 |
| TORQUE PARTS | TR9978 |
| WORLD AMERICAN | WA01-9978C |
