MAIN FILTER part description

Technical Specifications

Outside Diameter Top 2.756
Inide Diameter Top 1.595
Outside Diameter Bottom 2.756
BPVS Setting PSI 25
Collapse Pressure 44
Operating Temp Min F -13
Operating Temp Max F 248
Capacity gr 10.0998
Filter Area sq in 253
Flow Direction Outside-In
Gasket Material Viton
Fluid Type HH / HL / HM / HV
Beta Ratio 1 2/25
Micron 1 25

Features & Benefits

  • Interchange/replacement for OEM WIX p/n R19C25CBR
  • Compatible with OEM filter in fit, form and function
  • All of our elements are manufactured following ISO specifications.
  • Buy hydraulic filters direct from the manufacturer
  • Built using Quality Components with strict quality control.
  • Main Filter MF0599669 replaces OEM R19C25CBR by WIX and is compatible in fit, form and function.
  • All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
  • Images may be a general representations of products
  • Main Filter MF0599669 replaces OEM R19C25CBR by WIX and is compatible in fit, form and function.
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.

Features & Benefits

  • Interchange/replacement for OEM WIX p/n R19C25CBR
  • Compatible with OEM filter in fit, form and function
  • All of our elements are manufactured following ISO specifications.
  • Buy hydraulic filters direct from the manufacturer
  • Built using Quality Components with strict quality control.
  • Main Filter MF0599669 replaces OEM R19C25CBR by WIX and is compatible in fit, form and function.
  • All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
  • Images may be a general representations of products

Product Attributes

Height (in.) 8.45
Handle Yes
Wrap Yes
Bypass Yes
Micron Rating 25
Product Media Cellulose
Inside Diameter (Top) 1.6 in.
Maximum Operating Temperature 248 Deg Fahrenheit
Outside Diameter (Bottom) 2.76 in.
Minimum Operating Temperature -13 Deg Fahrenheit
Collapse Pressure 44
BPVS Setting (PSI) 24.7
Outside Diameter (Top) 2.76 in.
Filter Area (sq. in.) 253
Beta Ratio 1 2/25
Flow Direction Outside-In
Fluid Type HH / HL / HM / HV
Dust Holding Capacity 10.1 grams
Gasket Material Viton

Part Interchanges

MAIN FILTER MF0599669 Cross Reference

We have 1 alternatives for the MF0599669 by MAIN FILTER:
