Name: Main Filter MF0599669 Aftermarket Replacement Hydraulic Filter with 25 Micron Rating, Cellulose, Outside-In Flow
SKU: mf0599669
Price: 36.49 USD
Availability: InStock

MAIN FILTER part description

Technical Specifications

Outside Diameter Top	2.756
Inide Diameter Top	1.595
Outside Diameter Bottom	2.756
BPVS Setting PSI	25
Collapse Pressure	44
Operating Temp Min F	-13
Operating Temp Max F	248
Capacity gr	10.0998
Filter Area sq in	253
Flow Direction	Outside-In
Gasket Material	Viton
Fluid Type	HH / HL / HM / HV
Beta Ratio 1	2/25
Micron 1	25

Features & Benefits

Interchange/replacement for OEM WIX p/n R19C25CBR
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0599669 replaces OEM R19C25CBR by WIX and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products
Main Filter MF0599669 replaces OEM R19C25CBR by WIX and is compatible in fit, form and function.
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.

Features & Benefits

Interchange/replacement for OEM WIX p/n R19C25CBR
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0599669 replaces OEM R19C25CBR by WIX and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products

Product Attributes

Height (in.)	8.45
Handle	Yes
Wrap	Yes
Bypass	Yes
Micron Rating	25
Product Media	Cellulose
Inside Diameter (Top)	1.6 in.
Maximum Operating Temperature	248 Deg Fahrenheit
Outside Diameter (Bottom)	2.76 in.
Minimum Operating Temperature	-13 Deg Fahrenheit
Collapse Pressure	44
BPVS Setting (PSI)	24.7
Outside Diameter (Top)	2.76 in.
Filter Area (sq. in.)	253
Beta Ratio 1	2/25
Flow Direction	Outside-In
Fluid Type	HH / HL / HM / HV
Dust Holding Capacity	10.1 grams
Gasket Material	Viton

Part Interchanges

Wix R19C25CBR

MAIN FILTER MF0599669 Cross Reference

We have 1 alternatives for the MF0599669 by MAIN FILTER:

WIX R19C25CBR
