WABCO part description

Brake Chamber

Product Description

BRAKE CHAMBER 24

Product Attributes

Type 24
Return-Spring Force 175 N
Size 250 x 400 x 400
Port threads 3/8" - 18 NPTF
Push-rod thread 3/8"
Stroke 75.9 mm
Total Length 119.0 mm
Bolt Lengths 39.0 mm
Output Force 7500 N
Max. operating pressure 8.0 bar
Output Force M 7500 N
Max. operating pressure 116.0 psi
Calculated Volume (dm³) 40
Distance between bolts 120.6 mm
Temperature Range -40°C to +80°C
Weight 8.157
Yoke With
Version Without boot
Clevis Pins 12.9 mm
Type Of Operation Cam
Push-Rod Length 90.2 mm
Bolt Threads 5/8" - 11 UNC

WABCO 4231060070 Cross Reference

We have 2 alternatives for the 4231060070 by WABCO:

Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
