WABCO 9253470080 - Air Brake Chamber - Double Diaphragm Tristop 18/24
$20999
In stock
limited availability at this price!
. Learn more
WABCO part description
Product Attributes
| Max. operating pressure | 10.0 bar |
| Port Angle | 135° |
| Push-Rod Length | 15 mm |
| Return-Spring Force | 200 N |
| Type | 18/24 |
| Weight | 15 |
| Bolt Lengths | 43.0 mm |
| Total Length | 329.5 mm |
| Release Pressure | 5.1 bar |
| Stroke | 64.0 mm |
| Port thread 12 | 3/8" - 18 NPTF |
| Temperature Range | -40°C to +80°C |
| Distance between bolts | 120.6 mm |
| Push-rod thread | Ball R8 |
| Port thread 11 | 3/8" - 18 NPTF |
| Type Of Operation | Disc |
| Bolt Threads | M16 x 1.5 |
| Version | Without boot |
WABCO 9253470080 Cross Reference
We have 1 alternatives for the 9253470080 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
