(888) 312-8812 Login SignupWABCO 4784070710 ABS Modulator - DRY, without Blink Code
Tap to view 3 more
MSRP: $9,656.83
$6,79749
Save $2,859.34
+$625.00 core deposit
Total price w/ core: $7,422.49
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 4784070710 Part Description
Manufacturer
Product Description
HABS/ECU
WABCO ABS Modulator
Cycling air pressure rapidly to each brake chamber, the WABCO ABS Modulator stops wheel lockup before tires can flat-spot under hard braking. Internal design stays straightforward, keeping component count low across standard commercial trailer and truck setups alike. Fewer internal components mean fewer points of failure, so the modulator holds up through repeated daily duty cycles on regional and long-haul routes. Aggressive stops on slippery pavement still leave the chassis stable, since the modulator manages chamber pressure at each wheel independently. That consistent stability holds up on daily routes through the WABCO 4784070710 modulator.
Modulator
Features & Benefits
- Grips wet or icy pavement evenly as chamber pressure balances at each wheel
WABCO 4784070710 Specifications
Product Attributes
| Port thread RR | 1/2" - 20 UNF-2B |
| Port thread FR | 1/2" - 20 UNF-2B |
| Medium | Brake fluid FMVSS 116 |
| Protection class | IP 6K9K |
| Port thread RL | 7/16" - 24 UNS-2B |
| Distance Between Holes | 112x108/90 mm |
| Port thread MR | 1/2" - 20 UNF-2B |
| Size | 179 x 185 x 185 |
| Voltage | 12 V |
| Mounting | 3 x 3/8" - 16 UNC-2B |
| Weight | 12.125 |
| Calculated Volume (dm³) | 6.1263 |
| Temperature Range | -40°C to +85°C |
| Port thread MF | 7/16" - 24 UNS - 2B |
| Port thread FL | 7/16" - 24 UNS-2B |
WABCO 4784070710 Cross References
| Brand | Part Number |
|---|---|
| MERITOR | S4784070710 |
WABCO 4784070710 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 4784070710 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
