(888) 312-8812 Login SignupCENTRIC 320.45017F Centric GCX Rotor with Full Coating
Tap to view 4 more
$2699
Limited availability at this price!
1 Day Lead Time
Get it by Tuesday, Aug 11
CENTRIC 320.45017F Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
- For the best corrosion resistance
- RS200™ Zinc-Aluminum Rich Coating
- Optimal Surface Finish
- For consistent and confident braking from the first stop
- Carbon Enhanved Advanced Metallurgy
- For optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- For heat capacity and strength
- Low Initial Lateral Run-Out
- For smooth vibration free stopping
- Precision Balance
- For vibration free performance
CENTRIC 320.45017F Specifications
Product Attributes
| Product Grade [cntrc] | Premium |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 10.500 |
| Weight [cntrc] Kgs | 4.770 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Vane Style [cntrc] | Curved |
| Disc Mounting [cntrc] | Behind the Hub |
| Discard Thickness | 18.000 MM |
| Discard Thickness | 0.709 IN |
| Nominal Thickness | 0.787 IN |
| Nominal Thickness | 20.000 MM |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 20.000 MM |
| Overall Height | 0.787 IN |
| Outside Diameter | 10.079 IN |
| Outside Diameter | 256.000 MM |
| Mounting Bolt Hole Quantity | 6 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 3.386 IN |
| Center Hole Diameter | 86.000 MM |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Mounting Bolt Hole Diameter | 10.500 MM |
| Mounting Bolt Hole Diameter | 0.413 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590389890 |
CENTRIC 320.45017F Cross References
CENTRIC 320.45017F Fits Vehicles
- Mazda B2600 (1987-1993)
- Mazda B2200 (1987-1993)
- Mazda B2000 (1986-1987)
