RAYBESTOS 982495 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Coated Brake Rotor
Application Summary
2022-2018 Toyota C-HR Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 982495 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.441 IN |
| Center Hole Diameter | 62 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.984 IN |
| Discard Thickness | 25 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.331 IN |
| Inside Diameter | 186.2 MM |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.575 IN |
| Mounting Bolt Hole Diameter | 14.6 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 11.752 IN |
| Outside Diameter | 298.5 MM |
| Overall Height | 1.941 IN |
| Overall Height | 49.3 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213317336 |
RAYBESTOS 982495 Cross References
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH634628P |
| AutoZone | 71944DL |
| BrakeBest | 982495RGS |
| Brembo | 09.D417.11 |
| CENTRIC | 120.44201, 121.44201, 320.44201 |
| Centric Parts | 120.44201, 121.44201, 320.44201 |
| DURA CORP | BR901630 |
| DuraGo | BR901630 |
| Dynamic Friction Company | 604-76153 |
| MAGMA PRODUCTS | PSR563194 |
| Qualis | 44898 |
| TOYOTA | 43512F4010 |
| TopNotch | TN982495GEO |
| WORLDPAC | 1407-634628, 1427-634629 |
| Wagner Brake | BD180742E |
| Winhere | 6622293 |
RAYBESTOS 982495 Fits Vehicles
- Toyota C-HR (2018-2022)
