DORMAN BJ74184XL Part Description
Manufacturer
Product Description
Suspension Ball Joint
Application Summary
Lexus ES300h 2018-13, Lexus ES350 2018-07, Toyota Avalon 2018-05, Toyota Camry 2017-07
Features & Benefits
- Extended-life construction - this ball joint is built with features to deliver smooth performance and extended durability for demanding drivers
- Superior ball stud - hardened ArmourGrade stud with highly polished EverSmooth ball
- Low-friction bearing - UltraFlow normalized forged housing with I.C.E. synthetic grease and low-friction polymer bearing
- Premium corrosion resistance - WeatherShield external coating to resist corrosion
Suspension, Ball, Joint, Joints, Balls, Suspensions
DORMAN BJ74184XL Specifications
Product Attributes
| Material | Acero |
| Stud Thread Diameter | 14 MM |
| Castle Nut Included | Oui |
| Suspension Grade Type | Premium |
| Cotter Pin Hole | Oui |
| Mounting Hardware Included | Oui |
| Mounting Hole Quantity | 3 |
| Adjustable | Non |
| Greaseable | Non |
| Stud Type | Cono |
| Mounting Type | Con perno |
| Dust Boot Material | Policloropreno |
| Attachment Type | Cono |
| Bearing Material | Polímero |
| Bolts/Studs Included | Non |
| Package Contents | 1 Bolt |
| Thread Pitch | 1.50 |
| Length | 111 MM |
| Color | Gris |
| Width | 59 MM |
| Type | Roscado |
| Height | 85.03 MM |
| Wrench Size | 12 mm MM |
| Maximum Outside Diameter | 61 MM |
| Grease Fitting Included | Non |
| Bushings Included | Non |
| Dust Boot Included | Oui |
| Ball Joint Assembly | Oui |
| Cotter Pin Included | Non |
| Washers Included | Non |
| Nuts Included | Oui |
| Stud Thread Length | 35.5 MM |
| Bushing Quantity | 0 |
| Mounting Bolts Included | Non |
| Mount Plate Included | Non |
| Tapered Stud | Oui |
| Stud Taper Per Foot | 2 IN |
| Stud Tapered End 2 Diameter | 22 MM |
| Stud Tapered End 1 Diameter | 27.2 MM |
| Stud Thread Pitch | 1.5 MM |
| Ball Joint Installed | Oui |
| Bushing Included | Non |
| Housing Press Fit Diameter | 45 mm MM |
| Nuts Included | Oui |
| Stud Thread Pitch | 1.5 mm MM |
| Stud Thread Diameter | 14 mm MM |
Additional Information
| Country of Origin (Primary) | TH |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Warranty Special | Limited |
| Warranty Special UOM | LF |
| UPC | 00669810707822 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DORMAN BJ74184XL Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 1015839, 101-5839 |
| Centric Parts | 610.44030 |
| Delphi | TC2559 |
| MEVOTECH | MS86507 |
| MOOG | K500043 |
| MOOG Chassis Products | K500043 |
| Mcquay-Norris | FA2291 |
| Mevotech Original Grade | GS86507 |
| Mevotech Supreme | MS86507 |
| QuickSteer | K500043 |
| SUSPENSIA | X50BJ4014 |
| SYD | 1025014 |
| TRW | JBJ993 |
| Toyota | 4333009330, 4333009810, 4333039775, 4333039845 |
| XRF | K500043 |
| XRF Chassis | K500043 |
DORMAN BJ74184XL Fits Vehicles
- Lexus ES300h (2013-2018)
- Lexus ES350 (2007-2018)
- Toyota Camry (2007-2017)
- Toyota Avalon (2005-2018)
