Raybestos 980516R - Raybestos R-Line Brake Rotor
$6199
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
RAYBESTOS part description
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2009-2004 Audi S4 Rear
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68 MM |
| 9565 | Conventional |
| Discard Thickness | 0.787 IN |
| Discard Thickness | 20 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.644 IN |
| Inside Diameter | 194.15 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Diameter | 0.595 IN |
| Mounting Bolt Hole Diameter | 15.1 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.866 IN |
| Nominal Thickness | 22 MM |
| Outside Diameter | 11.806 IN |
| Outside Diameter | 299.85 MM |
| Overall Height | 1.415 IN |
| Overall Height | 35.95 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00887213286588 |
Part Interchanges
- Audi 8E0615601K
- Audi 8E0615601R
- Beck/Arnley 083-3275
- Brembo 09.A814.11
- Wagner Brake BD126452
- Wagner Brake BD126452E
- PowerStop EBR1014EVC
- BrakeBest 980516
- BrakeBest 980516RGS
- Centric Parts 121.33088
- Centric Parts 125.33088
- Centric Parts 125.33088CRY
- Centric Parts 126.33088CSL
- Centric Parts 126.33088CSR
- Centric Parts 126.33088SL
- Centric Parts 126.33088SR
- Centric Parts 127.33088CL
- Centric Parts 127.33088CR
- Centric Parts 127.33088L
- Centric Parts 127.33088R
- Centric Parts 128.33088CL
- Centric Parts 128.33088CR
- Centric Parts 128.33088L
- Centric Parts 128.33088R
- Advance Auto Parts YH200919
- Advance Auto Parts YH200919C
- Dura Corp BR34328
- Dura Corp BR900810
- Winhere 6620269
- Newtek Automotive USA 34328
- Newtek Automotive USA R810
- TRW 6005
- Promax 14-34328
- Centric Parts 120.33088
- DuraGo 900810
- DuraGo BR900810
- Qualis 34328
RAYBESTOS 980516R Cross Reference
We have 34 alternatives for the 980516R by RAYBESTOS:
- ADVANCE AUTO PARTS YH200919
- ADVANCE AUTO PARTS YH200919C
- AUDI 8E0615601K
- AUDI 8E0615601R
- BECK/ARNLEY 083-3275
- BRAKEBEST 980516
- BRAKEBEST 980516RGS
- BREMBO 09.A814.11
- CENTRIC 120.33088
- CENTRIC 121.33088
- CENTRIC 125.33088
- CENTRIC 125.33088CRY
- CENTRIC 126.33088CSL
- CENTRIC 126.33088CSR
- CENTRIC 126.33088SL
- CENTRIC 126.33088SR
- CENTRIC 127.33088CL
- CENTRIC 127.33088CR
- CENTRIC 127.33088L
- CENTRIC 127.33088R
- CENTRIC 128.33088CL
- CENTRIC 128.33088CR
- CENTRIC 128.33088L
- CENTRIC 128.33088R
- DURA CORP BR34328
- DURA CORP BR900810
- NEWTEK AUTOMOTIVE 34328
- NEWTEK AUTOMOTIVE R810
- POWERSTOP EBR1014EVC
- PROMAX 14-34328
- TRW 6005
- WAGNER BRAKE BD126452
- WAGNER BRAKE BD126452E
- WINHERE 6620269
Fits Vehicles
- Audi S4 (2004-2009)
