(888) 312-8812 Login SignupDELPHI TA2789 Tie Rod End
Tap to view 5 more
$4949
Limited availability at this price!
In Stock
Get it by Thursday, Feb 5
DELPHI TA2789 Part Description
Manufacturer
Product Description
Tie Rod End
Features & Benefits
- Delphi includes the necessary accessories for a complete job
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Delphi tie rods are fatigue tested to avoid failure
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TA2789 Specifications
Product Attributes
| Position(s) | At Pitman Arm, Left Outer. For the position specific to your vehicle, refer to the Applications. |
| Item Grade | Standard Replacement |
| Length | 187.00 MM |
| Color | Gray |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Grease Fitting Included | Yes |
| Dust Boot Included | Yes |
| Width | 43 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 14.00 MM |
| Height | 94.00 MM |
| Housing Material | Steel |
| Adjustable | No |
| Greaseable | Yes |
| Weight | 2.05 lb |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Grade | Premium |
| Stud Type | Threaded |
| End 2 Thread Pitch | 1.5 MM |
| Length - Stud Center to End | 165.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 1 Threads Per Inch | 18 |
| End 1 Thread Diameter | 1.000 IN |
| Grade Type | Standard Replacement |
| End 1 Thread Diameter | 25.40 MM |
| End 2 Thread Diameter | 0.551 IN |
| Length - Stud Center to End | 6.496 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | TR |
| UPC | 00689604296790 |
| VMRS Code | 015004020 |
| UNSPSC | 25174205 |
DELPHI TA2789 Cross References
DELPHI TA2789 Fits Vehicles
- Dodge Ram 3500 (1998-1999)
- Dodge Ram 2500 (1998-1999)
- Dodge Ram 1500 (1998-1999)
