(888) 312-8812 Login SignupFLEETGUARD LF9025 Lube Filter, Spin-On
MSRP: $480.18
$4549
Save $434.69
Limited availability at this price!
In Stock
Get as soon as Wednesday, Sep 23
FLEETGUARD LF9025 Part Description
Manufacturer
Features & Benefits
- Venturi design combines full-flow and bypass oil filtration in one unit
- Balances contaminant removal with low restriction to circulating engine oil
- Services both filtration paths together through one complete spin-on unit
- WorkStar N9 and N10 coverage defines a heavy-duty application context
Fleetguard Engine Oil Filter
During International WorkStar N9 and N10 lubrication service, the Fleetguard Engine Oil Filter combines full-flow and bypass filtration through a Venturi-style design. StrataPore media handles contaminant removal while the two-path arrangement balances oil cleaning with the need to keep lubricant moving through the engine. The Fleetguard LF9025 therefore serves a specific WorkStar N9 and N10 lubrication role rather than a generic spin-on application. Its service value comes from packaging both filtration paths and the media into one replaceable lube filter.
| Type | Spin On |
FLEETGUARD LF9025 Specifications
Product Attributes
| Capacity Test Specification | CECO 10765 IN |
| Gasket Inside Diameter | 4.00000216 IN |
| Gasket Outside Diameter | 4.6803056000000005 IN |
| Height | 13.87796025 in |
| Hydrostatic Burst Minimum | 304.935 IN |
| Largest Outside Diameter | 4.6803056000000005 IN |
| Media Type | Polymeric Meltblown (Stratapore/ Cvcoalescer) IN |
| Pressure Valve | No IN |
| Primary Particle Efficiency | 24.6 micron (c) @ 98.7% IN |
| Rated Flow | 39.629999999999995 IN |
| Thread Size | M95X2-7H IN |
FLEETGUARD LF9025 Cross References
| Brand | Part Number |
|---|---|
| FGLF9025, F7DZ7V000ARM | |
| BALDWIN | BD7250 |
| Baldwin | BK6652 |
| CARQUEST | 84744XD |
| Donaldson | P550656, P552025 |
| FRAM | PH9971, FPH9971, PH9971A |
| Hastings | LF597 |
| INTERNATIONAL | 1842639C91, 1841606C1 |
| INTERNATIONAL TRUCKS | 1841606C1 |
| International Harvester (IHC) | 1841606C1 |
| LUBER-FINER | LFP9025 |
| MACK | 5839LF9025, 3076PH9971 |
| N/A | 84744, SFO5025, BD7250 |
| NAPA | 7744XD, 7744 |
| NAVISTAR | 1842639C92 |
| Navistar | 1841606C1, 1842639C91 |
| PUROLATOR | L65965 |
| Sakura | C54060 |
| WIX FILTERS | 57744XD |
| Wix | 57744, 57744EC, 57744XD |
FLEETGUARD LF9025 Customer Reviews
No reviews yet
Be the first to review this product!
FLEETGUARD LF9025 Manufacturer Information
Since 1987, Fleetguard® has been one of the world's leaders in filtration solutions for both on- and off-highway applications. Whether it's air, fuel, oil, or hydraulic filtration, Fleetguard filters provide superior protection against contaminants for engines and sensitive equipment in the agriculture, construction, commercial vehicle, marine, mining, and power generation industries. Each filter is fitted with high-quality filter media for longer service life as well as a more compact design to accommodate shrinking engine compartments found in modern vehicles. All products also undergo extensive performance tests and strict quality control procedures to ensure durability and consistent performance, even in the most demanding operating conditions.
