ACDelco RW20-164 - Rear Wheel Bearing
$13499
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
ACDELCO part description
Technical Specifications
| Part Number | RW20-164 |
| weight | 7 lb 14 oz |
Product Description
Rear Wheel Bearing
Product Attributes
| Bearing Type | Ball |
| Flange Offset | 2.01 IN |
| Width | 4.78 IN |
| Flange Offset | 51 MM |
| Wheel Stud Size | 0.47 IN |
| Hub Pilot Diameter (in) | 2.7283 in |
| Flange Bolt Hole Quantity | 4 |
| Height (in) | 4.8 in |
| Wheel Pilot Diameter | 2.36 IN |
| Wheel Stud Quantity | 5 |
| Length (In) | 5.4 IN |
| Flange Included | Yes |
| Outside Diameter | 136 MM |
| Weight | 6.9 lb |
| Wheel Stud Size | 12 MM |
| Outside Diameter | 5.35 IN |
| Flange Diameter | 5.35 IN |
| Width | 121.38 MM |
| Hub Pilot Diameter (mm) | 69.3 mm |
| Bolt Circle Diameter | 105 MM |
| Flange Diameter | 136 MM |
| Product Description | ACDelco GM Original Equipment Wheel Bearings allow the wheel to rotate with minimal friction, and are GM-recommended replacements for your vehicle's original components. Wheel bearings support the weight of the vehicle and are lubricated with axle oil or wheel bearing grease. These original equipment wheel bearings have been manufactured to fit your GM vehicle, providing the same performance, durability, and service life you expect from General Motors. ⚠<b> WARNING:</b> Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Features & Benefits - Bullet 1 | Allows the wheel to rotate with minimal friction |
| Good Maintenance Practices - Section 1 - Bullet 1 | Be sure to have the bearing properly aligned when pressing it into the spindle assembly and do not overtighten center hub bearing to constant velocity shaft nut. |
| Anti Lock Braking System Type | Encoder |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 3 | Excessive play at tire and wheel |
| Good Maintenance Practices - Section 1 - Bullet 2 | Follow the manufacturers recommended torque specification. |
| Features & Benefits - Bullet 5 | GM OE bearing designs are dimensionally optimized to work with their mating parts |
| Features & Benefits - Bullet 4 | GM OE parts are built to help withstand potholes and designed to maximize seal life |
| Features & Benefits - Bullet 6 | GM-recommended replacement part for your GM vehicle's original factory component |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 1 | Grinding or humming noise from bearing assembly maybe more noticeable while turning |
| Features & Benefits - Bullet 8 | Manufactured to GM OE specification for fit, form, and function |
| Features & Benefits - Bullet 3 | Maximum lateral stiffness for optimum ride, handling, and driving dynamics |
| Programming Required | No |
| Flange Bolts Included | No |
| Features & Benefits - Bullet 7 | Offering the quality, reliability, and durability of GM OE |
| Flange Shape | Rectangular |
| Signs of Wear & Troubleshooting - Section 1 - Header | Signs of wear for wheel bearings include but are not limited to: |
| Features & Benefits - Bullet 2 | Supports the weight of the vehicle |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 2 | Tire and wheel vibration |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 4 | Wheel hot to the touch |
| Wheel Studs Included | Yes |
| Meets or Exceeds Original Equipment Manufacture Specifications | Yes |
| Anti Lock Braking System | Yes |
| Bolt Circle Diameter | 4.13 IN |
| Wheel Pilot Diameter | 60 MM |
| Brake Pilot Diameter | 5.35 IN |
| Brake Pilot Diameter | 136 MM |
| Flange Bolt Hole Diameter | 0.39 IN |
| Flange Bolt Hole Diameter | 10 MM |
Additional Information
| Warranty Special | 24 Months/Unlimited Miles Limited Warranty (Parts Only). Please see ACDelco.com for more details|36 Months/60,000 Kilometers Limited Warranty (Parts Only). Please see ACDelcocanada.com for more details |
| Harmonized Tariff Code (HTS) | 8708995800 |
| Country of Origin (Primary) | KR |
| Warranty Special UOM | TX |
| UPC | 00808709367185 |
Fits Vehicles
- Buick Encore (2013-2022)
- Chevrolet Trax (2013-2022)
- Chevrolet Sonic (2012-2020)
A true OEM auto parts brand for GM and non-GM vehicles, ACDelco® offers a wide portfolio of parts designed to keep vehicles on the road longer. These parts work precisely and fit perfectly because they are designed, engineered, tested, and backed by General Motors. But ACDelco also carries aftermarket components that go through the same 18-step quality approval process as the OE parts. Whether customers choose OE or aftermarket, they’d get the same reliable performance, precise engineering, and superior reliability for years to come. ACDelco’s expansive product portfolio includes alternators, filters, batteries, brakes, belts and hoses, oil and fluids, and suspension parts. These products are made to meet GM and non-GM vehicles’ ever-evolving powertrain, collision, maintenance, and repair needs.
