Item Grade	Standard Replacement
Position(s)	Front Lower
Material	Steel
Maximum Outside Diameter	2.614 IN
Maximum Outside Diameter	66.40 MM
Color	Black
Stud Thread Diameter	0.787 IN
Stud Thread Diameter	20 MM
Castle Nut Included	No
Grease Fitting Included	No
Suspension Grade Type	Standard
Bushings Included	No
Dust Boot Included	Yes
Ball Joint Assembly	Yes
Width	66.4 MM
Cotter Pin Included	No
Cotter Pin Hole	No
Mounting Hardware Included	Yes
Mounting Bolt Length	1.043 IN
Mounting Bolt Length	26.50 MM
Washers Included	No
Height	4.567 IN
Height	116.00 MM
Nuts Included	Yes
Mounting Hole Quantity	2
Adjustable	No
Greaseable	No
Stud Thread Length	1.358 IN
Stud Thread Length	34.5 MM
Wrench Size	50mm
Stud Type	Threaded
Distance Between Mounting Holes	90.00 MM
Dust Boot Material	Rubber
Mounting Bolt Shank Diameter	0.394 IN
Mounting Bolt Shank Diameter	10.00 MM
Mounting Bolt Head Diameter	0.689 IN
Mounting Bolt Head Diameter	17.50 MM
Mounting Bolts Included	Yes
Mounting Bolt Thread Pitch	1.5 MM
Mounting Bolt Thread Length	0.787 IN
Mounting Bolt Thread Length	20.00 MM
Mounting Bolt Thread Diameter	10.00 MM
Mount Plate Included	Yes
Tapered Stud	Yes
Stud Tapered End 2 Diameter	1.024 IN
Stud Tapered End 2 Diameter	26 MM
Stud Tapered End 1 Diameter	0.852 IN
Stud Tapered End 1 Diameter	21.65 MM
Stud Thread Pitch	1.5 MM
Length	113.00 MM
Length	4.450 IN
Mounting Bolt Thread Diameter	0.390 IN

Harmonized Tariff Code (Schedule B)	8708807000
Harmonized Tariff Code (HTS)	8708806590
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
Country of Origin (Primary)	TR
UPC	00689604290651
VMRS Code	016001015
UNSPSC	25174203

Delphi TC3675 - Ball Joint

Ball Joint
