WAGNER BD125405E Part Description
Manufacturer
Product Description
Disc Brake Rotor
Application Summary
1994-2004 Ford Mustang GT Base GTS (Front) (Qualifier: 5 Stud Wheel, with 276 (mm) Diameter Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion)
Features & Benefits
- ENGINEERED FOR PERFORMANCE -- OE-specific vane design provides effective braking power and heat dissipation while controlling noise, vibration and harshness
- OE-STYLE DESIGN -- Restores like-new braking performance while matching OE fit, form and function
- PREMIUM PROTECTION -- E-Shield(R) protective coating is applied to non-braking surfaces to inhibit corrosion
- RESISTS CORROSION -- Painted edges & hats provide reliable corrosion resistance
- TURNED AND SMOOTH FINISH -- Requires less pad break-in time and aids in proper bedding
- NON-DIRECTIONAL FINISH -- Reduces pad break-in time and promotes proper bedding for consistent stopping power
- EASY INSTALLATION -- Rotors are packaged in a Vapor Corrosion Inhibitor bag, eliminating the need for an oil coating which reduces prep time
- CONSISTENT PERFORMANCE -- Precision ground surface finish delivers reliable performance, noise reduction and heat dissipation
- PROPER BALANCE -- Spin balanced and cut to limit vibration for improving stability and control
- SMOOTH BRAKING -- Application-specific OE vane design and thickness help control noise, vibration and harshness (NVH)
- PERFECT PAIRING -- Pair Wagner premium rotors with premium brake pads for optimal performance
- BALANCED FOR SMOOTH STOPS -- Precision-balanced to minimize pedal pulsation and deliver a smoother ride
- QUALITY MATERIALS -- Proven metallurgy provides structural integrity and heat dispersion for reliable performance
- EASY TO INSTALL -- Simply wash the oil off and bolt on; no machining required
- COMPREHENSIVE COVERAGE -- Available for foreign and domestic nameplates
- PERFECT PAIRING -- Pair Wagner® Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
- PERFECT PAIRING -- Pair Wagner(R) Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
WAGNER BD125405E Specifications
Product Attributes
| Material | Cast Iron |
| Nominal Thickness | 26.1 MM |
| Disc Finish | Directional |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Outside Diameter | 276.4 MM |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Height | 47.0 MM |
| Part Description | Disc Brake Rotor |
| Height | 1.853 in |
| Stud/Lug Hole Quantity | 5 |
| Outside Diameter | 10.870 IN |
| Overall Height | 47.0 MM |
| Overall Height | 1.853 IN |
| Nominal Thickness | 1.029 IN |
| Bearings Included | No |
| Directional or Non-Directional Brake Surface | Non-Directional |
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.799 IN |
| Center Hole Diameter | 71.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.976 IN |
| Discard Thickness | 24.8 MM |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Diameter | 0.600 IN |
| Mounting Bolt Hole Diameter | 15.2 MM |
| Prop 65 Label (Yes/No) | No |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708305030 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00008536933557 |
| VMRS Code | 013017001 |
| UNSPSC | 25171715 |
WAGNER BD125405E Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 18A649 |
| Aimco | 54011 |
| Autospecialty | AR8141 |
| Bendix | 141911 |
| Bosch | 20010327 |
| Brembo | 27110 |
| CENTRIC | 120.61041 |
| Carquest | 54011, YH141911 |
| Centric Parts | 120.61041, 121.61041, 12061041, 12161041, 120.61041CRY, 320.61041F |
| DuraGo | BR54011, BR54011-01, BR54011-02 |
| Duralast | 54011, 54011DG |
| Dynamic Friction Company | 604-54033, 600-54033 |
| Ford | F4ZZ-1125-A, YR3Z1V125B, F4ZZ1125A |
| NAPA BRAKES | 86443CR, RA86443, 4886443, 24886443 |
| PowerStop | AR8141, AR8141EVC |
| Pro-Series | C25405, PS54011 |
| Promax | 20-54011, 14-54011 |
| RAYBESTOS | 66443, 66443R |
| Raybestos Brakes | 66443, 66443R, 66443FZN, 66443R2, 66443PER |
| Universal | 102140 |
| Worldparts Synergy | WS1154011 |
WAGNER BD125405E Fits Vehicles
- Ford Mustang (1994-2004)
