BALDWIN P7494 Part Description
Manufacturer
Product Description
Lube Element
Application Summary
International Engines, Trucks
Features & Benefits
- Cartridge-style element for engine-mounted canister housings
- Built without internal bypass valve components
- End-cap structure supports upper and lower seat compression
- Center tube dimensions match standpipe-style oil routing
Baldwin Engine Oil Filter
The Baldwin Engine Oil Filter is built for canister-style oil housings that depend entirely on the element’s height and center tube dimensions to control oil flow. Its overall length positions the end caps firmly against the upper housing cover and lower standpipe, directing oil through the media rather than around it. Because the housing manages bypass and drain-back functions externally, this element is constructed without internal valves that could disrupt that routing. The end-cap design and center tube structure are formed to compress evenly when the housing cap is secured, maintaining proper internal sealing pressure. The Baldwin P7494 is engineered to match the seating and flow requirements of reusable canister assemblies that rely on exact element fit.
BALDWIN P7494 Specifications
Product Attributes
| Replaces | Caterpillar 3809364; International 3007498C92, 3007543C92, 3015784C1 |
| Height | 7.625 |
| Remark 2 | & |
| Outside Diameter 1 (mm) | 119.9 |
| Outside Diameter 1 | 4.71875 |
| O-Ring | [1] Attached, [2] Included |
| Inside Diameter 1 (mm) | 44.4 |
| Inside Diameter 1 | 1.75 |
| Height (mm) | 193.7 |
| Fits | Caterpillar, IHC Trucks with MaxxForce 11, MaxxForce 13 Engines |
| Inside Diameter 2 (mm) | 53.2 |
| Inside Diameter 2 | 2 3/32 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8421230000 |
| UPC | 00791440090088 |
BALDWIN P7494 Cross References
| Brand | Part Number |
|---|---|
| 3007543C92, 3015784C1, BLDP7494 | |
| BALDWIN FILTERS | P7494 |
| CARQUEST | 84306 |
| CATERPILLAR | 3809364, 4725753 |
| CHAMPION LABORATORIES | LP7498XL |
| DONALDSON | P551088 |
| FLEETGUARD | LF17549, LF17519 |
| GRAINGER | 36VX04 |
| HASTINGS | LF672 |
| IHC INTERNATIONAL HARVESTER | 3015784C1, 3007543C94, 3007543C93, 3007543C92, 3007539C1, 3007498C94, 3007498C93, 3007498C92, 3015784C2 |
| INTERNATIONAL | 3007498C92 |
| JURA (HIFI) | SO7255 |
| LUBER-FINER | LP7498XL |
| MANN+HUMMEL | HU1291, HU12002 |
| NAPA GOLD | 7306, 400047 |
| PREMIUM GUARD | HG50105 |
| SAKURA | EO54020 |
| SURE FILTER TECHNOLOGY | SFO1088E |
| UNIFLUX | XOE766 |
| WIX | WL10047, 57306 |
| WIX FILTERS | WL10047 |
BALDWIN P7494 Fits Vehicles
- International HX520 (2025)
- International HX620 (2022-2024, 2026)
- International HX515 (2017-2022)
- International HV613 (2019-2024, 2026)
- International HV513 (2019-2025)
- International RH613 (2018-2024)
- International HX615 (2017-2022)
- International LT625 (2018-2024)
- International 7600 (2009-2017)
- International LoneStar (2013-2014)
- International 8600 TranStar (2008-2018)
- International WorkStar 7600 (2009-2014, 2017-2019)
- International ProStar (2008-2019)
- Caterpillar CT680 (2015)
- Caterpillar CT660 (2011-2017)
