(888) 312-8812 Login SignupRAYBESTOS 982045 Raybestos Specialty - Street Performance Coated Brake Rotor
$52.43
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 982045 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Coated Brake Rotor
Application Summary
2023-2018 Toyota Camry Rear, 2021-2019 Toyota RAV4 Rear, 2022-2018 Toyota C-HR Rear, 2021-2018 Lexus NX300 Rear, 2017-2015 Lexus NX200t Rear, 2023-2019 Lexus ES350 Rear, 2023-2021 Toyota Venza Rear, 2022-2019 Toyota Avalon Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 982045 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.4 IN |
| Center Hole Diameter | 62.0 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.4 IN |
| Discard Thickness | 10.5 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.6 IN |
| Inside Diameter | 192.5 MM |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.6 IN |
| Mounting Bolt Hole Diameter | 14.5 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.5 IN |
| Nominal Thickness | 12.0 MM |
| Outside Diameter | 11.1 IN |
| Outside Diameter | 281.0 MM |
| Overall Height | 1.7 IN |
| Overall Height | 44.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Material | Cast Iron |
| Bearings Included | No |
| Construction | Full Cast |
| Grade Type | Regular |
| Maximum Brake Diameter (Discard) | 281.0 MM |
| Rust Resistant Coating | Yes |
| Weight [cntrc] Kgs | 4.6 |
| Weight [cntrc] Lbs | 10.2 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213219135 |
RAYBESTOS 982045 Cross References
| Brand | Part Number |
|---|---|
| ADVICS | A6R1065 |
| AUTOXTRA | AX901454, AX901632 |
| AUTOZONE | 71930 |
| AutoZone | 71930DG, 71930DL |
| Autoxtra | AX901454P, AX901632P |
| BRAKEBEST | 912100RGS, 982045, 982045R |
| Brembo | 08.D418.11, 08.D418.1X |
| CENTRIC | 120.44195, 121.44195, 126.44195SL, 126.44195SR, 127.44195L, 127.44195R, 128.44195L, 128.44195R, 320.44195 |
| Centric Parts | 120.44195, 121.44195, 126.44195SL, 126.44195SR, 127.44195L, 127.44195R, 128.44195L, 128.44195R, 320.44195 |
| DURA CORP | BR901454, BR901632 |
| DuraGo | BR901454, BR901632, BR901632-01 |
| Dynamic Friction Company | 600-75041, 604-75041 |
| Lexus | 4243178010 |
| MAGMA PRODUCTS | PMR565190, PSR565190 |
| NEOTEK | 1063099GF |
| NEWTEK AUTOMOTIVE | R1454 |
| Newtek Automotive USA | R1454 |
| PEP BOYS | 901632G |
| POWERSTOP | JBR1738EVC |
| PROMAX | 14-610047 |
| Qualis | 44880 |
| TOYOTA | 4243106180, 4243106190, 4243178010, 42431F4010 |
| TopNotch | TN982045GEO |
| WAGNER BRAKE | BD180741 |
| WINHERE | 6612100 |
| WORLDPAC | 1407-524448, 1427-566205 |
| Wagner Brake | BD180741E, BD180792E |
RAYBESTOS 982045 Fits Vehicles
- Lexus UX300h (2025)
- Toyota Prius Prime (2023-2024)
- Toyota Prius (2023-2025)
- Toyota Prius AWD-e (2023-2024)
- Toyota Corolla Cross (2022-2025)
- Lexus ES250 (2021-2025)
- Toyota Venza (2021-2024)
- Lexus UX250h (2019-2024)
- Lexus UX200 (2019-2022)
- Lexus ES350 (2019-2025)
- Lexus ES300h (2019-2025)
- Toyota RAV4 (2019-2025)
- Toyota Avalon (2019-2022)
- Lexus NX300 (2018-2021)
- Toyota Camry (2018-2025)
- Toyota C-HR (2018-2022)
- Lexus NX200t (2015-2017)
- Lexus NX300h (2015-2021)
