(888) 312-8812 Login SignupCENTRIC 320.62071 Centric GCX Rotor with Partial Coating
Tap to view 4 more
$6549
Limited availability at this price!
In Stock
Get it by Thursday, Dec 18
CENTRIC 320.62071 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.62071 Specifications
Product Attributes
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Lbs | 15.500 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 193.000 |
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Kgs | 7.050 |
| Max Pb Drum Dia [cntrc] In | 7.598 |
| Disc Mounting [cntrc] | Floating / DIH |
| Vane Style [cntrc] | Pillar |
| Discard Thickness | 24.000 MM |
| Discard Thickness | 0.945 IN |
| Nominal Thickness | 1.024 IN |
| Nominal Thickness | 26.000 MM |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 48.000 MM |
| Overall Height | 1.890 IN |
| Outside Diameter | 11.732 IN |
| Outside Diameter | 298.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 7.480 IN |
| Nominal Drum Diameter | 190.000 MM |
| Bearings Included | No |
| Center Hole Diameter | 70.500 MM |
| Center Hole Diameter | 2.776 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.800 MM |
| Stud/Lug Hole Diameter | 0.504 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590301823 |
CENTRIC 320.62071 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 580102, 580102FZN, 580102R |
