CENTRIC 320.65056 Centric GCX Rotor with Partial Coating

★★★★★ (0)
Centric 320.65056 Disc Brake Rotor and Hub Assembly Centric GCX Rotor with Partial Coating
CENTRIC
Tap to view 4 more

$99.12

MSRP Pricing shown.

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

CENTRIC 320.65056 Part Description

Manufacturer

CENTRIC

Product Description

Centric GCX Rotor with Partial Coating

Features & Benefits

  • RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs

CENTRIC 320.65056 Specifications

Product Attributes

Inner Seal # [cntrc]417.65000
California Proposition 65 Text [cntrc]WARNING: Cancer and Reproductive Harm
Weight [cntrc] Kgs12.730
Inner Bearing # [cntrc]410.91018
Disc Mounting [cntrc]Hub & Rotor
Weight [cntrc] Lbs28.000
Misc Holes [cntrc]0
Vane Style [cntrc]Straight
Outer Bearing # [cntrc]410.91012
Product Grade [cntrc]Premium
Discard Thickness24.700 MM
Discard Thickness0.972 IN
Nominal Thickness25.700 MM
Nominal Thickness1.012 IN
Disc FinishPartially Coated
Hat FinishCoated
Stud Thread Diameter12.000 MM
Overall Height104.000 MM
Overall Height4.094 IN
ABS Tone Ring IncludedYes
Surface TypeSmooth
Rotor Outside Diameter308.000 MM
Rotor Outside Diameter12.126 in
Solid Or Vented Type RotorVented
Bolt Thread Pitch1.750 MM
Bearings IncludedNo
Center Hole Diameter86.800 MM
Center Hole Diameter3.417 IN
Mounting Bolt Hole Circle Diameter135.000 MM
Mounting Bolt Hole Circle Diameter5.315 IN
Stud/Lug Hole Quantity5

Additional Information

Harmonized Tariff Code (HTS)8708305030
NAFTA Preference Criterion CodeB
Country of Origin (Primary)CN
UPC00889590302066

CENTRIC 320.65056 Cross References

BrandPart Number
RAYBESTOS66822, 66822R
Raybestos Brakes66822, 66822R
