MERITOR MAF9471 Part Description
Manufacturer
Product Description
Air Suspension Spring
Meritor Air Suspension Spring
Stabilize air-ride load support with the Meritor Air Suspension Spring. The reversible-sleeve construction and bead plate layout make this spring a complete air-ride component for suspension positions that need controlled height, load cushioning, and road-shock absorption. Its max-height and bead-plate dimensions help confirm the spring before installation without turning the PDP into a spec sheet. The Meritor MAF9471 is a practical air spring choice for trailers or trucks with suspension service built around this sleeve-style spring design.
| Bead Plate Diameter Bottom | 10.25 in. |
| Bead Plate Diameter Top | 9.00 in. |
| Collapsed Height | 9.70 in. |
| Convoluted Style | 1T Reversible Sleeve |
| Max. Height | 24.50 in. |
| Part Diameter | 10.12 in. |
| Piston Height | 7.57 in. |
| Stud Configuration-Bottom | 1 |
| Stud Configuration-Top | 2 |
| Stud Mount-Bottom Flat | Stud |
| Stud Mount-Top Flat | Stud |
| VMRS Code | 016-008-001 |
Meritor Air Suspension Spring
Meritor air suspension spring protects tractors and trailers from road shocks and keep your ride a comfortable one. This aftermarket air spring covers a wide range of OEM specifications at affordable prices.
Features & Benefits
- Lightweight, high-strength pistons with support washers provide exceptional strength and durability
- Made of premium-grade steel and aluminum with electrostatic coating for oxidation resistance
- Special chromium coating on bead plate protects against rust, corrosive chemicals, and harsh operating environments
- Absorbs road shock before it travels through the chassis
MERITOR MAF9471 Specifications
Product Attributes
| Bead Plate Diameter Bottom | 10.25 in. |
| Bead Plate Diameter Top | 9.00 in. |
| Brand | Meritor |
| Collapsed Height | 9.70 in. |
| Convoluted Style | 1T Reversible Sleeve |
| Max. Height | 24.50 in. |
| Pallet Quantity | 27 |
| Part Diameter | 10.12 in. |
| Piston Height | 7.57 in. |
| Stud Configuration-bottom | 01 |
| Stud Configuration-top | 02 |
| Stud Mount-bottom Flat | Stud |
| Stud Mount-top Flat | Stud |
| Weight | 16.10 |
| Air Spring Type | Reversible Sleeve |
| Max Height | 24.50 in. |
MERITOR MAF9471 Cross References
| Brand | Part Number |
|---|---|
| 90557146, 90557182, 90557212, AB1DK23P9471, BP1845, FAW013589471, FSIW013589471, HL90557212, SAF90557212, TDAMAF9471 | |
| AUTOMANN | AB1DK23P9471, AB1DK23P-9471 |
| Automann | 566ER9471 |
| CONTITECH | 910175P502, 9 10-17.5 P 502 |
| Continental-ContiTech | 910175P502 |
| DAYTON PARTS | 452-9471L |
| DAYTON PARTS BATCO | 3529471 |
| FIRESTONE | W013589471 |
| FLAGG | 8502 |
| Firestone Ride-Rite | W013589471 |
| GOODYEAR | 1R12372 |
| GOODYEAR/STEMCO | 1R12372 |
| SAF HOLLAND | 90557146 |
| SAF-HOLLAND | 90557146 |
| TRIANGLE | 8502 |
