(888) 312-8812 Login SignupFLEETGUARD HF35201 Hydraulic Filter, Cartridge
$5699
3 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
FLEETGUARD HF35201 Part Description
Manufacturer
| Attributes | |
|---|---|
| Largest Outside Diameter | 70 mm (2.756 inch) |
| Largest End Inside Diameter | 28.7 mm (1.13 inch) |
| Gasket Inside Diameter | 27.6 mm (1.087 inch) |
| Flow Direction | Outside In |
| BPV Setting | No |
| Particle Size at Beta 75 | 45.0 micron |
| Product Comments | |
| delivered without spring |
FLEETGUARD HF35201 Specifications
Product Attributes
| Gasket Inside Diameter | 1.070864 IN |
| Gasket Outside Diameter | 1.3488162 IN |
| Largest End Inside Diameter | 1.1299190000000001 IN |
| Largest Outside Diameter | 2.7559 IN |
| Overall Height | 3.5236150000000004 in |
| Particle Size at Beta 75 | 35.0 IN |
| Rated Flow | 5.284 IN |
FLEETGUARD HF35201 Cross References
| Brand | Part Number |
|---|---|
| FGHF35201, HC3Z14401EC | |
| BALDWIN | PT9180 |
| LUBER-FINER | LH11010V |
| MAIN FILTER | MF0585645 |
| MP FILTRI | MF1001P10NB |
| N/A | 1457431601, P171521, PT9180, 94105, CR501, R120C10B, 154939, TIE16101, F6P10A, 7603402, RE15CD1, 7604100, WGH9505, SH63305, ALH16009, 943709Q, 7131654, F6P10, Y05773805, FPE0710N, TIE12P101, HF171527 |
| WIX FILTERS | R17C10CB |
FLEETGUARD HF35201 Customer Reviews
No reviews yet
Be the first to review this product!
FLEETGUARD HF35201 Manufacturer Information
Since 1987, Fleetguard® has been one of the world's leaders in filtration solutions for both on- and off-highway applications. Whether it's air, fuel, oil, or hydraulic filtration, Fleetguard filters provide superior protection against contaminants for engines and sensitive equipment in the agriculture, construction, commercial vehicle, marine, mining, and power generation industries. Each filter is fitted with high-quality filter media for longer service life as well as a more compact design to accommodate shrinking engine compartments found in modern vehicles. All products also undergo extensive performance tests and strict quality control procedures to ensure durability and consistent performance, even in the most demanding operating conditions.
FLEETGUARD HF35201 Questions & Answers
No questions yet
Be the first to ask a question about this product!
