Haldex GC3030LS7CW - 3030 GOLD SEAL
$13099
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
HALDEX part description
Product Description
Type 3030, GoldSeal, Welded Clevis, 3.0" Stroke, Standard housing
Application Summary
3030 Combination Lng Stroke Welded Clevis 4.20
Features & Benefits
- Uses superior power spring technology for unparalleled force output consistency
- Has powder-coated housing that effectively resists fatigue and corrosion
- World-class diaphragm that’s made of high-quality rubber compound for superior flexibility and heat- and cold-resistance
- With rugged powder-coated service housing for corrosion protection
- Self-piloting dust shield extends air brake system lifespan
- Comes in a variety of sizes to fit all drum brake applications
Haldex GoldSeal Air Brake Spring Brake
Equip your vehicle with a high-quality Haldex GoldSeal air brake spring brake. This product is the only truly sealed double diaphragm spring brake specifically designed for heavy duty applications.
Product Attributes
| Bracket to End of Spring Housing Length | 9.88 in. |
| Clevis Pin Length | 4.2 in. |
| Freight Class | 70 |
| Piggyback Length | 7.42 in. |
| Series | GoldSeal |
| Service Chamber Size | 30/30 |
| Service Clampband Size | 10.19 in. |
| Spring Housing Flange Size | 8.26 in. |
| Stroke Length | 3 in. |
| Stroke Type | Long |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8412310080 |
| Harmonized Tariff Code (HTS) | 8412310080 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | See Haldex Aftermarket Product warranty Policy (L20221W).pdf |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653370149 |
| VMRS Code | 013004027 |
California residents see Prop 65 Warning(s)
