Delphi TC2932 - Control Arm and Ball Joint Assembly
$13399
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Control Arm and Ball Joint Assembly
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Upper |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Steel |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 3.299 IN |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.472 IN |
| Ball Joint Thread Diameter | 12.00 MM |
| Ball Joint Stud Length | 0.925 IN |
| Ball Joint Stud Length | 23.50 MM |
| Control Arm Maximum Length | 12.520 IN |
| Control Arm Maximum Length | 318.00 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Bushings Included | Yes |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Control Arm Maximum Width | 83.79 MM |
| Thread Diameter | 12.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.472 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604269350 |
| VMRS Code | 016001002 |
| UNSPSC | 25172013 |
Part Interchanges
- Beck/Arnley 101-5782
- Beck/Arnley 102-5782
- MOOG Chassis Products CK641529
- MOOG Chassis Products K641529
- MOOG Chassis Products RK620336
- MOOG Chassis Products RK641529
- Mevotech CMS86171
- Toyota 48630-39055
- Toyota 4863039015
- MAS Industries CB64027
- MAS Industries CB64027PR
- Dorman 520-593
- TRW JTC7596
- CMS86105
- GS86105
- 520-457
Fits Vehicles
- Lexus SC430 (2002-2010)
- Lexus GS430 (2001-2005)
- Lexus GS400 (1998-2000)
- Lexus GS300 (1993-2005)
