DELPHI TC1663 Part Description
DELPHI TC1663 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Lower |
| Material | Ball Material - Alloy Steel SAE 5140, Housing Material - Carbon Steel SAE 1040 |
| Maximum Outside Diameter | 2.205 IN |
| Maximum Outside Diameter | 56.00 MM |
| Color | Gray |
| Stud Thread Diameter | 0.75 IN |
| Castle Nut Included | No |
| Grease Fitting Included | Yes |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 56 MM |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | Yes |
| Height | 4.094 IN |
| Nuts Included | Yes |
| Adjustable | No |
| Greaseable | Yes |
| Stud Thread Length | 0.945 IN |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Mounting Bolts Included | No |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Taper Per Foot | 0.125 IN |
| Stud Tapered End 2 Diameter | 0.878 IN |
| Stud Tapered End 2 Diameter | 22.3 MM |
| Stud Tapered End 1 Diameter | 0.996 IN |
| Stud Tapered End 1 Diameter | 25.3 MM |
| Stud Threads Per Inch | 16 |
| Length | 4.090 IN |
| Length | 104.00 MM |
| Stud Thread Diameter | 19.05 MM |
| Height | 103.99 MM |
| Stud Thread Length | 24 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604276822 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC1663 Cross References
| Brand | Part Number |
|---|---|
| DORMAN | B8435, B8435PR |
| Ford | E0TZ-3050B, F6TZ-3050GA |
| MAS Industries | B8435 |
| MOOG | K8435 |
| MOOG Chassis Products | K8435 |
| Mevotech | MK8435 |
| N/A | F6TZ 3050-EA, GK8435 |
| TRW | JBJ7010 |
DELPHI TC1663 Fits Vehicles
- Ford F-250 HD (1997)
- Ford F-350 (1980-1985)
- Ford F-250 (1980-1996)
