(888) 312-8812 Login SignupMONROE 5540 OESpectrum Suspension Shock Absorber
Tap to view 5 more
MSRP: $86.74
$4999
Save $36.75
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
MONROE 5540 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5540 Specifications
Product Attributes
| Lower Mount Code | LS29 |
| Upper Mount Code | S1 |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Body Diameter | 1.519 IN |
| Compressed Length | 16.34 IN |
| Extended Length | 25.76 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.3/4" Sleeve OAL |
| Parts Pack(s) | P01682 |
| Travel Length | 9.42 in |
| Upper Mount Type | Stem Mount - Stem Length X M10 Thread Pitch |
| Compressed Length | 415 MM |
| Extended Length | 654.3 MM |
| Travel Length | 239.3 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Body Diameter | 38.6 MM |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS29 |
| Upper Mount Type | Stem Mount - Stem Length X M10 Thread Pitch |
| Upper Mount Code | S1 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598192288 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5540 Cross References
| Brand | Part Number |
|---|---|
| Autopart International | 2701662905 |
| Duralast | TS3240222B |
| FCS | 346443 |
| Gabriel | 70207 |
| KYB | 3430041 |
| KYB AMERICA LLC. | 3430041 |
| MasterPro Shocks and Struts | MZ105 |
| Mazda | BABF28700B, BABF28910A, BABF28910B, BABF34700, BABF34900, BABH34700B, BABH34900B, BACS28700, BACS34700, BACS34900, BHN228910B, BHN234700C, BHN234900C, BHP734700, BHP734900, BJS728700F, BJS734700D, BJS734900D |
| Monroe Shocks & Struts | 210016 |
| NAPA Shocks | 5540, NS5540 |
| OEM | BJS728700F, BABF28700B, BHN228910B |
| PM Auto | PM6001527 |
| TRQ | SBA72159 |
| Top Quality | 785540 |
MONROE 5540 Fits Vehicles
- Mazda 3 (2014-2018)
MONROE 5540 Customer Reviews
No reviews yet
Be the first to review this product!
MONROE 5540 Questions & Answers
No questions yet
Be the first to ask a question about this product!
