(888) 312-8812 Login SignupDELPHI TC3038 Control Arm and Ball Joint Assembly
Tap to view 2 more
MSRP: $281.09
$23999
Save $41.10
Limited availability at this price!
In Stock
Get it by Thursday, Feb 12
DELPHI TC3038 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC3038 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Upper |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Aluminum |
| Mounting Hardware Included | No |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 3.945 IN |
| Control Arm Maximum Width | 100.20 MM |
| Control Arm Color | Gray |
| Control Arm Maximum Length | 12.008 IN |
| Control Arm Maximum Length | 305.00 MM |
| Bushing Material | Rubber |
| Mounting Hole Diameter | 0.039 IN |
| Mounting Hole Diameter | 1.00 MM |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604270998 |
| VMRS Code | 016001002 |
| UNSPSC | 25172013 |
DELPHI TC3038 Cross References
| Brand | Part Number |
|---|---|
| DORMAN | CB35068PR, CB35068 |
| MEVOTECH | CMS101430 |
| MEYLE | 53160500028HD |
| MOOG | RK622953 |
| N/A | GS101430, CMS101430, JPLA3084GB, DPLA3084AB |
| Rover | LR0 44841, LR113262 |
| VAICO | V480474 |
DELPHI TC3038 Fits Vehicles
- Land Rover Range Rover (2020-2022)
- Land Rover Discovery (2017-2022)
- Land Rover Range Rover Sport (2014-2022)
