(888) 312-8812 Login SignupDELPHI TC286 Control Arm and Ball Joint Assembly
Tap to view 9 more
MSRP: $71.22
$6199
Save $9.23
Limited availability at this price!
In Stock
Get it by Thursday, Feb 5
DELPHI TC286 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC286 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower Rearward |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 1 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 2.756 IN |
| Control Arm Maximum Width | 70.00 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 14.00 MM |
| Ball Joint Stud Length | 60.00 MM |
| Control Arm Maximum Length | 14.764 IN |
| Control Arm Maximum Length | 375.00 MM |
| Mounting Hole Diameter | 12.20 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 14.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Ball Joint Thread Diameter | 0.551 IN |
| Ball Joint Stud Length | 2.362 IN |
| Thread Diameter | 0.551 IN |
| Mounting Hole Diameter | 0.480 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604258866 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC286 Cross References
| Brand | Part Number |
|---|---|
| BMW | 3112 1124 401, 3112 1131 587, 3112 1139 991 |
| Beck/Arnley | 101-4127, 102-4127 |
| CORTECO | 49399195 |
| DORMAN | CB9127, CB9127PR |
| Dorman | 520-733 |
| MAS Industries | CB9127, CB9127PR |
| MEYLE | 3160504217 |
| MOOG | RK9127 |
| MOOG Chassis Products | CK9127, K9127, RK9127 |
| Mcquay-Norris | FA1525 |
| Mevotech | CMK9127, MK9127 |
| N/A | GK9127, 31121127401 |
| TRW | JTC258 |
| VAICO | V20-7033-1 |
DELPHI TC286 Fits Vehicles
- BMW M6 (1987-1988)
- BMW M5 (1988, 1991-1993)
- BMW 750iL (1988-1999)
- BMW 740i (1993-1994)
- BMW 735iL (1988-1992)
- BMW 735i (1987-1992)
- BMW 635CSi (1985-1989)
- BMW 633CSi (1983-1984)
- BMW 540i (1994-1995)
- BMW 535i (1985-1993)
- BMW 533i (1983-1984)
- BMW 528e (1982-1988)
- BMW 525i (1989-1990, 1995)
- BMW 524td (1985-1986)
