(888) 312-8812 Login SignupDELPHI TC2590 Control Arm and Ball Joint Assembly
Tap to view 2 more
MSRP: $656.92
$35949
Save $297.43
Limited availability at this price!
In Stock
Get it by Wednesday, Feb 25
DELPHI TC2590 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC2590 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Aluminum |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 3 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 16.339 IN |
| Control Arm Maximum Width | 415.00 MM |
| Control Arm Color | Gray |
| Ball Joint Stud Length | 3.701 IN |
| Ball Joint Stud Length | 94.00 MM |
| Control Arm Maximum Length | 18.583 IN |
| Control Arm Maximum Length | 472.00 MM |
| Mounting Hole Diameter | 0.555 IN |
| Mounting Hole Diameter | 14.10 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Uncoated |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604258156 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC2590 Cross References
| Brand | Part Number |
|---|---|
| Audi | 7L8 407 152 D, 7L8 407 152 E, 7L8 407 152 F, 7L8 407 152 K |
| Beck/Arnley | 102-7568 |
| CORTECO | 49398553 |
| DORMAN | CB12104, CB12104PR |
| Dorman | 521-956 |
| MAS Industries | CB12104, CB12104PR |
| MEYLE | 116 050 0097, 1160500097S, 116 050 0190 S, 116 050 0191 S |
| MOOG Chassis Products | K620457, RK620153, RK620457, 102-7568 |
| Mevotech | CMS70125 |
| N/A | GS70125, CK620457, 623.33102 |
| TRW | JTC2314 |
| VAICO | V10-0893 |
DELPHI TC2590 Fits Vehicles
- Volkswagen Touareg (2007-2008)
- Audi Q7 (2007-2010)
