DELPHI FG2113 Fuel Pump Module Assembly

★★★★★ (0)

$445.49

Limited availability at this price!

5 Day Lead Time

Get as soon as Tuesday, Dec 1
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details
This item will ship about 5 days after the date of purchase.

DELPHI FG2113 Part Description

Manufacturer

DELPHI

Product Description

Fuel Pump Module Assembly

Features & Benefits

  • Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
  • Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
  • Lower amperage draws less load on vehicle's electrical system
  • Part is validated, tested and matched to the right vehicle application
  • Always be sure to check and clean fuel tank to avoid unnecessary returns
  • Lower failure rates due to its innovative design and durability

DELPHI FG2113 Specifications

Product Attributes

Outlet Outside Diameter0.313 IN
Voltage12 2H
Fuel TypeGas
Regulator IncludedYes
Terminal TypeBlade
Gasket Or Seal IncludedYes
Terminal Quantity9
Lock Ring IncludedNo
Terminal GenderMale
Strainer IncludedYes
Inlet TypeStrainer
Outlet TypeQuick Connect
Outlet Quantity2
In Tank or ExternalIn Tank
Resistance Ohms Empty300 82
Resistance Ohms Full15 82
Internal Or External StrainerInternal
Average Current Draw13 68
Pump TypeElectric
Fuel Level Sender Assembly IncludedYes
Item GradeStandard Replacement
Package ContentsFuel Pump Module Assembly w/Float Arm, Instruction Sheet
Vapor Pressure SensorYes
Fuel Sending Unit IncludedYes
Negative GroundNo
Maximum Pressure81 PS
Mounting Hardware IncludedNo
Universal Or Specific FitSpecific
Grade TypePremium
Connector Quantity1
Connector ShapeRectangle
Housing MaterialPlastic
Installation WarningsNo
Connector GenderFemale
Fuel Filter IncludedYes
Gasket Or Seal MaterialNitrile Rubber
Minimum Pressure73 PS
Wire Harness IncludedNo
Pump DesignTurbine
Fuel Tank Pressure Sensor IncludedYes
Average Flow Rating31 GPH

Additional Information

Country of Origin (Primary)TH
Harmonized Tariff Code (Schedule B)8413309000
Harmonized Tariff Code (HTS)8708998180
Remanufactured PartN
Warranty SpecialLimited
Warranty Special UOMLT
UPC00689604285497
VMRS Code044003258
UNSPSC25172409

DELPHI FG2113 Cross References

BrandPart Number
AutoZoneDFG2113
Hyundai31120-D3500, 31370-C3000, 94460-D3500
Kia31120-D3500, 31370-C3000
N/AUSEP21034M
STANDARD IGNITIONPR603

DELPHI FG2113 Fits Vehicles

  • Hyundai Tucson (2016-2020)
  • Kia Sportage (2016-2022)
