(888) 312-8812 Login SignupDELPHI TC2463 Control Arm and Ball Joint Assembly
Tap to view 2 more
MSRP: $125.28
$10749
Save $17.79
Limited availability at this price!
In Stock
Get it by Thursday, Jun 18
DELPHI TC2463 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC2463 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Press In |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 1.748 IN |
| Control Arm Maximum Width | 44.40 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.472 IN |
| Ball Joint Thread Diameter | 12.00 MM |
| Ball Joint Stud Length | 0.748 IN |
| Ball Joint Stud Length | 19.00 MM |
| Control Arm Maximum Length | 8.272 IN |
| Control Arm Maximum Length | 210.10 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 12.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.472 IN |
Additional Information
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604270578 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC2463 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-5766, 102-5766 |
| CORTECO | 49400162 |
| DORMAN | CB74283, CB74283PR |
| Dorman | 521-105 |
| MAS Industries | CB74283, CB74283PR, CB74284 |
| MOOG Chassis Products | K201307, K620572, RK620572, 102-5766, K201351, K500118 |
| Mevotech | CMS86138, MK80349 |
| N/A | 48069-59125, 4806909040, 4806959145, GS86138, CK620572, 622.44054 |
| TRW | JTC7654 |
| Toyota | 48069-59095, 48069-59135 |
| VAICO | V700093 |
DELPHI TC2463 Fits Vehicles
- Toyota Prius C (2012-2019)
- Scion xD (2008-2014)
- Toyota Yaris (2006-2019)
