DELPHI TC1845 Part Description
Manufacturer
Product Description
Ball Joint
Features & Benefits
- Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
- Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC1845 Specifications
Product Attributes
| Position(s) | Front Lower |
| Item Grade | Standard Replacement |
| Material | Steel |
| Maximum Outside Diameter | 1.685 IN |
| Maximum Outside Diameter | 42.80 MM |
| Color | Black |
| Castle Nut Included | No |
| Grease Fitting Included | Yes |
| Suspension Grade Type | Standard Replacement |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 60 MM |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Mounting Bolt Length | 2.461 IN |
| Mounting Bolt Length | 62.50 MM |
| Washers Included | No |
| Height | 3.343 IN |
| Height | 84.90 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 3 |
| Adjustable | No |
| Greaseable | Yes |
| Wrench Size | 19mm |
| Distance Between Mounting Holes | 58.00 MM |
| Dust Boot Material | Rubber |
| Mounting Bolt Shank Diameter | 0.472 IN |
| Mounting Bolt Shank Diameter | 12.00 MM |
| Mounting Bolt Head Diameter | 0.866 IN |
| Mounting Bolt Head Diameter | 22.00 MM |
| Mounting Bolts Included | Yes |
| Mounting Bolt Thread Pitch | 1.75 MM |
| Mounting Bolt Thread Length | 1.181 IN |
| Mounting Bolt Thread Length | 30.00 MM |
| Mounting Bolt Thread Diameter | 12.00 MM |
| Mounting Bolt Thread Diameter | 0.470 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604254257 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC1845 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-6749 |
| DORMAN | BJ92145, BJ92145XL, 535-821 |
| Deeza | BC-G602 |
| General Motors | 19 13 3670 |
| Isuzu | 8191336700 |
| MAS Industries | B6663, BJ92145 |
| MEVOTECH | MS50517, TXK6663 |
| MOOG | K6663 |
| MOOG Chassis Products | K500083, K6663 |
| Mcquay-Norris | FA2200 |
| Mevotech | MK6663 |
| N/A | 22 15 7319, 15140718, MS50517, GK6663, TXK6663, BJ92145XL, 610.66021 |
| Raybestos Chassis | 505-1296 |
| Saab | 19 13 3670 |
| TRW | JBJ847, JBJ1182 |
DELPHI TC1845 Fits Vehicles
- Chevrolet Trailblazer EXT (2002-2006)
- GMC Envoy XL (2002-2006)
- GMC Envoy XUV (2004-2005)
- Saab 9-7x (2005-2009)
- Chevrolet SSR (2003-2006)
- Buick Rainier (2004-2007)
- Oldsmobile Bravada (2002-2004)
- GMC Envoy (2002-2009)
- Chevrolet Trailblazer (2002-2009)
- Isuzu Ascender (2003-2008)
