(888) 312-8812 Login SignupDELPHI TC1008 Control Arm and Ball Joint Assembly
Tap to view 2 more
MSRP: $101.49
$8349
Save $18.00
Limited availability at this price!
In Stock
Get it by Friday, Jun 26
DELPHI TC1008 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC1008 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Press In |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 1 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 3.823 IN |
| Control Arm Maximum Width | 97.10 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.472 IN |
| Ball Joint Thread Diameter | 12.00 MM |
| Ball Joint Stud Length | 0.748 IN |
| Ball Joint Stud Length | 19.00 MM |
| Control Arm Maximum Length | 15.764 IN |
| Control Arm Maximum Length | 400.40 MM |
| Mounting Hole Diameter | 0.728 IN |
| Mounting Hole Diameter | 18.50 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 12.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.472 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604250396 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC1008 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-4763, 101-7697, 101-7715, 102-4763 |
| CORTECO | 49399440 |
| DORMAN | CB74014, CB74014PR |
| Dorman | 52-2102, 520-432 |
| MAS Industries | CB74014, CB74014PR |
| MOOG Chassis Products | CK620364, K500118, K620364, RK620364, 101-7697, 101-7715, 102-4763 |
| Mevotech | CMS86101, MK90310 |
| N/A | RK622149, GS86101, 48068-19175 |
| TRW | JTC990 |
| Toyota | 48068-19176, 48068-59035 |
| VAICO | V221007 |
DELPHI TC1008 Fits Vehicles
- Scion xB (2004)
- Scion xA (2004)
- Toyota MR2 Spyder (2000-2005)
- Toyota Echo (2000-2003)
