(888) 312-8812 Login SignupDELPHI TA3009 Tie Rod End
Tap to view 2 more
MSRP: $34.43
$3099
Save $3.44
Limited availability at this price!
In Stock
Get it by Thursday, Dec 18
DELPHI TA3009 Part Description
DELPHI TA3009 Specifications
Product Attributes
| Position(s) | Left Outer |
| Item Grade | Standard Replacement |
| Color | Black |
| End 2 Gender | Female |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | Yes |
| Width | 65.3 MM |
| Type | Bent |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.551 IN |
| End 2 Thread Diameter | 14.00 MM |
| Height | 72.00 MM |
| Housing Material | Steel |
| Tube Diameter | 0.866 IN |
| Tube Diameter | 22.00 MM |
| Adjustable | No |
| Greaseable | No |
| Weight | 1.75 lb |
| Cone Outside Diameter | 15.10 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Stud Type | Threaded |
| End 2 Thread Pitch | 1.5 MM |
| Length - Stud Center to End | 7.992 IN |
| Length - Stud Center to End | 203.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 0.472 IN |
| End 1 Thread Diameter | 12.00 MM |
| Shank Length | 15.10 MM |
| Stud Length | 15.10 MM |
| Grade Type | Standard |
| Grade | Premium |
| Shank Length | 0.594 IN |
| Stud Length | 0.594 IN |
| Cone Outside Diameter | 0.594 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604249765 |
| VMRS Code | 015004020 |
| UNSPSC | 25174205 |
DELPHI TA3009 Part Interchanges
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-5750 |
| MOOG Chassis Products | ES800240 |
| Mevotech | MS60600 |
| Honda | 53560-SNA-A01 |
| MAS Industries | TO59131 |
| Import Direct | ER04018 |
| N/A | 53560-SNE-A01, ES800374, 53560-SNE-A02, TXMS60600, JTE1437, GS60600 |
DELPHI TA3009 Fits Vehicles
- Honda Civic (2006-2011)
