Delphi TA1734 - Tie Rod End
$2899
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Tie Rod End
Product Attributes
| Position(s) | Inner |
| Item Grade | Standard Replacement |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | No |
| Width | 36 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 12.00 MM |
| Height | 36.00 MM |
| Housing Material | Steel |
| Tube Diameter | 0.571 IN |
| Tube Diameter | 14.50 MM |
| Adjustable | No |
| Greaseable | No |
| Weight | 1.06 lb |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| End 2 Thread Pitch | 1.25 MM |
| Length - Stud Center to End | 9.937 IN |
| Length - Stud Center to End | 252.40 MM |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 16.00 MM |
| Grade Type | Standard |
| Locking Nut Included | Yes |
| Grade | Premium |
| End 2 Thread Diameter | 0.472 IN |
| End 1 Thread Diameter | 0.630 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604245996 |
| VMRS Code | 015004070 |
| UNSPSC | 25174205 |
Part Interchanges
- Beck/Arnley 101-4217
- MOOG Chassis Products EV322
- Mcquay-Norris ES2922X
- Mevotech MEV322
- Deeza NI-A616
- Datsun/Nissan 48521-50400
- Datsun/Nissan 48521-50Y00
- Datsun/Nissan 48521-50Y25
- Datsun/Nissan 48521-Y02G0
- MAS Industries IS322
- TRW JAR146
- Import Direct AX07136
- GEV322
- 4852185F00
- 4852150Y27
- 4852150Y26
- IS322PR
Fits Vehicles
- Nissan NX (1991-1993)
- Nissan Sentra (1991-1999)
