Delphi TA1589 - Tie Rod End
$2199
MSRP: $25.92
Save: $3.93
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Tie Rod End
Product Attributes
| Position(s) | Left Outer |
| Item Grade | Standard Replacement |
| Color | Gray |
| End 2 Gender | Female |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | Yes |
| Width | 50.8 MM |
| Type | Bent |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.551 IN |
| End 2 Thread Diameter | 14.00 MM |
| Height | 68.50 MM |
| Housing Material | Steel |
| Tube Diameter | 0.669 IN |
| Tube Diameter | 17.00 MM |
| Adjustable | No |
| Greaseable | No |
| Weight | 1.74 lb |
| Cone Outside Diameter | 14.10 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Stud Type | Threaded |
| End 2 Thread Pitch | 1.5 MM |
| Length - Stud Center to End | 8.504 IN |
| Length - Stud Center to End | 216.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 0.394 IN |
| End 1 Thread Diameter | 10.00 MM |
| Shank Length | 14.10 MM |
| Stud Length | 14.10 MM |
| Grade Type | Standard |
| Grade | Premium |
| Shank Length | 0.555 IN |
| Stud Length | 0.555 IN |
| Cone Outside Diameter | 0.555 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604245491 |
| VMRS Code | 015004020 |
| UNSPSC | 25174205 |
Part Interchanges
- Beck/Arnley 101-4619
- MOOG Chassis Products ES3153
- MOOG Chassis Products ES3392R
- MOOG Chassis Products ES3490
- Mcquay-Norris ES3153
- Mevotech MES3153
- Mevotech MES3392R
- Mevotech MES3490
- Deeza HN-T614
- Honda 53560-S1A-E01
- Honda 53560-SM4-003
- Honda 53560-SM4-004
- Honda 53560-SN4-004
- Honda 53560-SV4-003
- MAS Industries T3153
- MAS Industries T3392
- MAS Industries T3490
- Rover GSJ407
- TRW JTE306
- Import Direct ER04002
- Import Direct ER05003
- Import Direct ER05018
- MOOG Chassis Products 101-4619
- GES3153
- GES3490
- T3153PR
- T3490XL
Fits Vehicles
- Honda Accord (1990-1993, 1998-2002)
- Acura TL (1999-2003)
- Acura CL (2001-2003)
- Isuzu Oasis (1996-1999)
