(888) 312-8812 Login SignupRAYBESTOS 980084FZN Raybestos Element3 Coated Brake Rotor
$51.43
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980084FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2004-1999 Volvo S40 Front, 2004-1999 Volvo V40 Front
Features & Benefits
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology for long lasting rust prevention.
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 980084FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.717 IN |
| Center Hole Diameter | 69 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.846 IN |
| Discard Thickness | 21.5 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.487 IN |
| Mounting Bolt Hole Diameter | 12.35 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24 MM |
| Outside Diameter | 11.063 IN |
| Outside Diameter | 281 MM |
| Overall Height | 1.791 IN |
| Overall Height | 45.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 4 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213228458 |
RAYBESTOS 980084FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | 832816, YH145440, YH145440C, YH145440P |
| AUTOSPECIALTY | EBR644, EBR644E |
| AUTOXTRA | AX34210 |
| AUTOZONE | 34210, 34210DG, 34210DL |
| BECK/ARNLEY | 083-2815 |
| BENDIX | 145440 |
| BRAKEBEST | 52011352, 81-126176, 980084, 980084FZN, 980084R, 980084RGS, BD126176 |
| BREMBO | 09.7720.10, 09.7720.11, 25517 |
| Brembo | 09.7720.75 |
| CENTRIC | 120.39027, 121.39027, 125.39027, 126.39027CSL, 126.39027CSR, 126.39027SL, 126.39027SR, 127.39027CL, 127.39027CR, 127.39027L, 127.39027R, 128.39027CL, 128.39027CR, 128.39027L, 128.39027R, 320.39027H |
| Casting Numbers | 325975 |
| Centric Parts | 120.39027, 121.39027, 125.39027, 126.39027CSL, 126.39027CSR, 126.39027SL, 126.39027SR, 127.39027CL, 127.39027CR, 127.39027L, 127.39027R, 128.39027CL, 128.39027CR, 128.39027L, 128.39027R, 320.39027H |
| DURA CORP | BR34210 |
| DuraGo | BR34210 |
| MIGHTY DISTRIBUTING SYSTEM | 34210 |
| NAPA BRAKES | SDK6106, TSR886 |
| NEWTEK AUTOMOTIVE | 34210 |
| Newtek Automotive USA | 34210 |
| PAGID | 355112171 |
| PAGID Racing | 355112171 |
| PILENGA | V262 |
| POWERSTOP | EBR644EVC |
| PROMAX | 14-34210 |
| QUALIS | 34210 |
| QUINTON HAZELL | BDC4572 |
| TRUSTAR | 421240 |
| TRW | DF4054S |
| UAP | 34210 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51616 |
| VOLVO | 30818027, 308180270, 308180272 |
| WABCO | PS126176 |
| WABCO - Archived | PS126176 |
| WAGNER BRAKE | BD126176 |
| WINHERE | 442831 |
| WORLDPAC | 1407-78655 |
RAYBESTOS 980084FZN Fits Vehicles
- Volvo V40 (1999-2004)
- Volvo S40 (1999-2004)
