Centric 123.44054 - C-Tek Standard Brake Drum
$3949
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Kgs | 4.455 |
| Weight [cntrc] Lbs | 9.800 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 55.000 |
| Hub Hole / Register [cntrc] In | 2.165 |
| Height [cntrc] Mm | 55.300 |
| Height [cntrc] In | 2.177 |
| Friction Surface Width [cntrc] Mm | 38.900 |
| Friction Surface Width [cntrc] In | 1.531 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 201.000 MM |
| Maximum Brake Diameter (Discard) | 7.913 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 240.000 MM |
| Outside Diameter | 9.449 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.800 MM |
| Mounting Hole Diameter | 0.504 IN |
| Nominal Drum Diameter | 199.800 MM |
| Nominal Drum Diameter | 7.866 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590178876 |
Part Interchanges
CENTRIC 123.44054 Cross Reference
We have 1 alternatives for the 123.44054 by CENTRIC:
Fits Vehicles
- Toyota Yaris iA (2017-2018)
- Scion iA (2016)
- Toyota Yaris (2019-2020)
- Mazda 2 (2016-2022)
