RAYBESTOS 981772 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2022-2021 Kia K5 Rear, 2016-2014 Kia Cadenza Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 981772 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.992 IN |
| Center Hole Diameter | 76 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.331 IN |
| Discard Thickness | 8.4 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.031 IN |
| Inside Diameter | 204 MM |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.492 IN |
| Mounting Bolt Hole Diameter | 12.5 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.394 IN |
| Nominal Thickness | 10 MM |
| Outside Diameter | 11.181 IN |
| Outside Diameter | 284 MM |
| Overall Height | 1.22 IN |
| Overall Height | 31 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Diameter | 0.492 IN |
| Stud/Lug Hole Diameter | 12.5 MM |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213170719 |
RAYBESTOS 981772 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH504544, YH504544C, YH504544P |
| AUTOZONE | 70121, 70121DG, 70121DL |
| BRAKEBEST | 981772, 981772FZN, 981772R |
| CENTRIC | 120.50029, 120.50029CRY, 121.50029, 126.50029SL, 126.50029SR, 127.50029L, 127.50029R, 128.50029L, 128.50029R, 320.50029 |
| Centric Parts | 120.50029, 120.50029CRY, 121.50029, 126.50029SL, 126.50029SR, 127.50029L, 127.50029R, 128.50029L, 128.50029R, 320.50029 |
| Dura Corp | BR901430, BR901430-01 |
| DuraGo | BR901430, BR901430-01 |
| Dynamic Friction Company | 604-21014 |
| KIA | 584113R700 |
| MAGMA PRODUCTS | PSR283046 |
| NEOTEK | 1069045GF |
| Qualis | 44766 |
| WORLDPAC | 1407-504544, 1427-613653 |
| Wagner Brake | BD180703E |
| Winhere | 661960 |
RAYBESTOS 981772 Fits Vehicles
- Kia K5 (2021-2022)
- Kia Cadenza (2014-2016)
