(888) 312-8812 Login SignupMONROE 5515 OESpectrum Suspension Shock Absorber
MSRP: $104.69
$7499
Save $29.70
Limited availability at this price!
In Stock
Get it by Tuesday, Feb 24
MONROE 5515 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5515 Specifications
Product Attributes
| Lower Mount Code | LS57 |
| Upper Mount Code | S8 |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 16.35 IN |
| Extended Length | 25.83 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 20MM Sleeve ID X 2" Sleeve OAL |
| Parts Pack(s) | P01682 |
| Travel Length | 9.48 in |
| Upper Mount Type | Stem Mount - 1" Stem Length X M8 Thread Pitch |
| Compressed Length | 415.3 MM |
| Extended Length | 656.1 MM |
| Travel Length | 240.8 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS57 |
| Upper Mount Code | S8 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598168849 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5515 Cross References
| Brand | Part Number |
|---|---|
| Autopart International | 2701698817 |
| GABRIEL | 70110 |
| KYB | 349246, 3440014 |
| KYB AMERICA LLC. | 3440014 |
| Mazda | GJR928910G, GJR928910H, GJR934700C, GJR934900C |
| Monroe Shocks & Struts | 210005 |
| NAPA Shocks | 5515 |
| OEM | GJR928910G |
| PRT | 373383 |
| Sachs | 318465 |
| TRW | JGT5688S |
MONROE 5515 Fits Vehicles
- Mazda 6 (2014)
