MONROE 5532 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5532 Specifications
Product Attributes
| Lower Mount Code | LS28 |
| Upper Mount Code | S4 |
| Dust Shield Included | Yes |
| Includes Bump Stop | Yes |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Body Diameter | 1.751 IN |
| Compressed Length | 18.72 IN |
| Extended Length | 20.23 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.5/8" Sleeve OAL |
| Parts Pack(s) | P01136 |
| Travel Length | 1.51 in |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Compressed Length | 475.5 MM |
| Extended Length | 513.8 MM |
| Travel Length | 38.4 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Body Diameter | 44.5 MM |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS28 |
| Upper Mount Code | S4 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598182142 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5532 Cross References
| Brand | Part Number |
|---|---|
| Datsun/Nissan | E43024AF0A, E43029AM0A, E43029AM0B, E43034AF0A, E43039AM0A, E43039AM0B, E62104AF0A, E62109AM0A |
| Duralast | TS3239842B |
| FCS | 346239 |
| FCS AUTO PARTS | 346239 |
| GABRIEL | G511044 |
| KYB | 3440012 |
| KYB AMERICA LLC. | 3440012 |
| MasterPro Shocks and Struts | NS116 |
| Monroe Shocks & Struts | 210013 |
| NAPA Shocks | 5532, NS5532 |
| Nissan | E62104AF0A, E62109AM0A |
| OEM | E62109AM0A, E62104AF0A |
| SENSEN | 1213-0614 |
| Sachs | 316328 |
| Sensen | 12130614 |
| UNITY AUTOMOTIVE | 255350, 2-255350-001 |
| Ultra Spring Seat | G511044 |
MONROE 5532 Fits Vehicles
- Nissan Sentra (2014-2019)
