(888) 312-8812 Login SignupFRAM CH11794 Cartridge Oil Filter
Tap to view 5 more
MSRP: $21.95
$2049
Save $1.46
Limited availability at this price!
In Stock
Get it by Friday, Jan 30
FRAM CH11794 Part Description
Manufacturer
Product Description
FRAM, CH11794, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- The perfect balance of dirt-trapping efficiency and dirt-holding capacity
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines
Cartridge Oil Filter
FRAM CH11794 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 4.882 IN |
| Grade Type | Regular |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Grade | Advanced |
| Housing Color | NA |
| Inside Diameter Bottom | 1.713 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring Inside Diameter | 2.913 IN |
| O-ring Outside Diameter | 3.054 IN |
| O-ring Thickness | 0.141 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 2.972 in |
| Outer Diameter Top | 2.972 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 1.024 in |
| Torque Nut | No |
| Washable | No |
Additional Information
| Country of Origin (Primary) | KR |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100555380 |
| UNSPSC | 15121001 |
FRAM CH11794 Cross References
| Brand | Part Number |
|---|---|
| AFE | 44-LF035-MB, 44LF035 |
| BALDWIN | P7517 |
| Carquest | 94206 |
| Carquest Premium Filters | 94206 |
| Champ | P1014 |
| Chrysler | 68109834AA, 68229402AA, 68492616AA |
| Defense Filters | DL11794 |
| ECOGUARD | X10232 |
| FRAM | TG11794 |
| FRAM Drive | FD11794 |
| FRAM Tough Guard | TG11794 |
| FRAM Ultra Synthetic | XG11794 |
| FVP | G68109834AA |
| Factory Motor Parts | G68109834AA |
| Fiat | K68109834AA, K68229402AA |
| Firestone | P1014 |
| Hastings | LF696 |
| Jura Filtration | SO8044 |
| LUBER-FINER | P1014 |
| MAHLE | OX1145D |
| MANN-HUMMEL FILTERS | HU7018Z |
| MicroGard Select | MSL10060 |
| Mobil | P1014 |
| NAPA | 100060 |
| NAPA ProSelect Filters | 2100060 |
| PARTS PLUS | P1014EX |
| PREMIUM GUARD | PG8157EX |
| PUREPRO | L38157, PL8157, PL91014 |
| PUROLATOR | TL38157 |
| Parts Master | WL610060 |
| Pennzoil | PZ189 |
| Performax | PO-189 |
| Premium Guard Extended Life | PG8157EX |
| Prime Guard Filters - Archived | POF8157 |
| Purolator | L38157 |
| STP | S11794 |
| STP Filters | S11794, S11794XL |
| Service Champ | CF8157, WP1014 |
| Sofima | S1079PE |
| UFI | 25.079.01 |
| Valvoline | VO-142 |
| WIX FILTERS | WL10060 |
| Warner | WP1014 |
| Warner Filters | WP1014 |
| Wix | WL10060 |
FRAM CH11794 Fits Vehicles
- Suzuki Aerio (2002)
- Ram 1500 Classic (2019)
- Jeep Grand Cherokee (2014-2020)
- Ram 1500 (2014-2018)
