Dayco 5120477 - SERPENTINE BELT
$5949
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DAYCO part description
Product Description
POLY RIB BELT, DAYCO
Product Attributes
| Rib Quantity | 12 |
| Top Width | 1.66 in |
| Effective Length | 47.716 in |
| Effective Length | 1211.99 mm |
| Outside Circumference | 48.275 in |
| Outside Circumference | 1226.19 mm |
| Rib Profile | Straight Rib |
| Material | EPDM, Aramid Reinforced |
| Cross Section | K-Section |
| Rib Depth | Standard |
| Color | Black |
| Standards | SAE J1459, SAE J2432 |
| Minimum Operating Temperature | -42.7 C |
| Maximum Operating Temperature | 100 C |
| Minimum Operating Temperature | -45 F |
| Maximum Operating Temperature | 212 F |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4010313000 |
| UPC | 00036687910424 |
Part Interchanges
- BANDO 12PK1210
- NAPA 25-120477HD
- NAPA 25120477
- NAPA POWERFIT 25120477
- NAPA POWERFIT 25120477HD
- Continental Elite 4120476F
- Continental Elite 4120476X
- PACCAR D84-1002-121212
- DYNACRAFT D84-1003-121212
- GATES K120476
- GATES K120476HD
- GATES (Canada) K120477
- GATES (Canada) K120477HD
- AC DELCO NA
- CARQUEST NA
- BANDO NA
- CONTITECH NA
- MASTERPRO NA
- GOODYEAR NA
- CADNA NA
DAYCO 5120477 Cross Reference
We have 2 alternatives for the 5120477 by DAYCO:
Fits Vehicles
- Peterbilt 365 (2016-2017, 2019-2020)
- Peterbilt 587 (2015-2018)
- Peterbilt 579 (2014-2023)
- Peterbilt 367 (2015-2017)
- Kenworth T880 (2014-2023)
- Kenworth T680 (2015-2022)
- Kenworth T660 (2014-2018)
- Peterbilt 567 (2015-2023)
- Peterbilt 384 (2014-2016)
- Kenworth W900 (2015-2016)
- Kenworth T800 (2014-2022)
